Cable Distribution Box, European Type

Request a Quote

View All: http://hvpower-equip.com/2-3-cable-distribution-box-european-type/index.html

European type cable distribution boxes do not have switches, and they are also known as ordinary cable distribution boxes. This equipment is widely used in power distribution network systems around the world. The box has a double swing door and busbar connection. It is compact and features a clear cable arrangement with a three-core cable to eliminate the need for long-span crossing. The cable joint adopted by the box meets DIN47636 standards. The cable joint adopted is a 630 bolt fixing connection type of rate current.

Application

European type cable distribution box is cabling engineering equipment widely used in power distribution network systems.

Technical Parameters

Rated Voltage (KV): 12

Rated Current (V): 690

1min Power-Frequency Withstand Voltage (KV): 42

Thermal Current (KA): 15-50

Dynamic Current (KA): 40-125

Lighting Impulse Withstand Voltage (KV): 75-105

Features

Full insulation, full enclosure, full safeguard for worry free operation

In-out wire is flexible: there are at most 8 branches of in-out wire

European type cable distribution box is anti-flood, anti-pollution, anti-condensation, and corrosion resistant

It is compact in structure, easy to install, and easy to operate

It can be equipped with a zinc oxide arrester

It can be equipped with a potential indicator

The equipment can be outfitted with a cable fault indicator, in order to find out the cable fault rapidly.

Application Environment

Maximum Air Temperature: 40 ℃

Minimum Air Temperature: -30 ℃

Wind Speed: 34m/s (less than 700 Pa)

Relative Humidity daily average value is no more than 95%

Ground Surface Horizontal Acceleration: Lower than 0.4 m/s2

Ground Surface Vertical Acceleration: Lower than 0.1m/s2

Installation Site Inclination: ≤3 degrees

The surrounding air should be free from corrosive and combustible gases, and there should be no severe vibration at the installation site.
