Loading-Unloading System
Request a Quote
Model: AM-SXL-20
JDL loading-unloading system is designed for the manufacturing of molded inductor, which automatically feeds inductors, trims molded inductor and automatically unloads them after testing and packing. A PLC control system and warning system ensures the production safety during the operation and improves the efficiency of assembly line.
Product Details:
Technical Parameters
| Feeder | Magazine |
| Unloading Mode | Pallet/Magazine(optional) |
| Application | Molded inductor or injection molded parts |
| Accuracy | 0.02mm |
| Capacity | 0.6-0.8 Kpcs/h |
| Working temperature | -5℃-50℃ |
| Machine size(L*W*H) | 1200(L)*800(W)*1800(H)mm |
| Power supply | Single phase, AC220V/50HZ |
| Air supply | 0.4-0.6mpa |
| Power consumption | 5kW |
| Weight | 400kg |
