ARC MMA Welder / Inverter Welding Machine
Request a Quote
ARC 400GT
Features
- Stable welding performance: market proven performance, improved technology, providing high arc stability and welding reliability;
- Long-time welding: max. output current 380A, high duty cycle, continuous welding of Ø4.0/5.0mm E6013, E7018, E7016, E6011 acid and basic electrodes, a good choice for industrial applications;
- Extension cable: the welder can automatically adjust the output voltage to compensate the loss, able to work with extension cable of up to 100 meters;
- Professional functions: with meter display, built-in anti-stick, adjustable arc force and hot arc start, satisfying the application needs of different welding positions;
- Dust free cooling system: efficiently cutting down on the dust amount and prolonging the service life, able to adapt to harsh environments;
- Anti-shock protection: VRD anti-shock design protects operator against electric shocks, reducing no-load voltage and ensuring work safety;
- Classic design: classic appearance design, multiple functions, and with corner protectors;
Specifications
Model | |
Input voltage | 3PH 380V (±15%) |
Frequency | 50/60Hz |
Rated power | 18.2kVA |
Duty cycle (40℃) | 40% |
No-load voltage (with VRD) | 15V |
No-load voltage (without VRD) | 62V |
Current adjusting range | 40-380A |
Hot start adjusting range | 0-10 |
Arc force adjusting range | 0-10 |
Efficiency | 85% |
Power factor | 0.93 |
Protection grade | IP21 |
Insulation class | Class H |
Anti-shock protection | Class I |
Electromagnetic Compatibility (EMC) | A |
Static characteristic | Drooping characteristic |
Cooling method | Forced air cooling |
Net weight (kg) | 18.5kg |
Dimensions (L×W×H) | 508×244×423mm |
Package Included
- Welding cable quick connector, 2pcs
- Allen key, 1pc
Welding Effect
MMA welding fillet joint in horizontal position
MMA welding fillet joint in vertical position
Applications
- Suitable for welding carbon steel, stainless steel, copper plates, with good weld quality;
- Compact size and lightweight, easy to carry and take to any jobsites;
- Strong capability of adapting to mains voltage fluctuation, sufficient output of welding current, better welding stability;
- Rebar welding
- Excavator part welding
- Pipeline welding
- I-beam welding
- Steel structure
- Steel angle welding
- 3mm-thick carbon steel vertical fillet welding (2.5 welding rod)
- 5mm-thick carbon steel vertical fillet welding (3.2 welding rod)
- Carbon steel fillet welding (4.0 welding rod)
- Carbon steel fillet welding (5.0 welding rod)
- 15mm-thick steel plate welding (5.0 welding rod)
- Pipeline welding (4.0 welding rod)
- 3mm-thick steel angle welding (3.2 welding rod)
Optional Welding Accessories
Ground clamp & cable assembly
Auto-darkening welding helmet
Electrode holder & cable assembly
Welding gloves
Welding chipping hammer
