JDY’s tines are compatible with a variety of lawn aerator machines. Tines are produced by experienced engineers who are experts in understanding the requirements of lawn maintenance equipment performance.

With an excellent working effect and smooth inner and outer tine edges, the required mowing rate for lawn maintenance is easily met.

During lawn maintenance and punching processes, sand in the holes is unable to be completely removed, which often leads to local deformation of the lawn and bottom layer knots. JDY’s tines minimize the punching and actuality on the lawn, so that the sand volume removed is reduced, thus reducing customer operating costs.

Tine Specifications

JDY Deep Tines
JDY PN.	Length	Mount	Tip O.D	Tip I.D
JDT180121611	180mm	12mm	16mm	11mm
JDT220121611	220mm	12mm	16mm	11mm
JDT245243223	245mm	24mm	32mm	23mm
JDT245183223	245mm	18mm	32mm	23mm
JDT250121912.5	250mm	12mm	19mm	12.5mm
JDT250181912.5	250mm	18mm	19mm	12.5mm
JDT300121912.5	300mm	12mm	19mm	12.5mm
JDT300181912.5	300mm	18mm	19mm	12.5mm
JDT300172516.5	300mm	17.8mm	25mm	16.5mm

Notes:

Tines can be customized according to your specific requirements.
