Solid Tines

Request a Quote

View All: http://lawnmowingparts.com/3-1-solid-tines.html

JDY’s tines are compatible with a variety of lawn aerator machines. Tines are produced by experienced engineers who are experts in understanding the requirements of lawn maintenance equipment performance.

With an excellent working effect and smooth inner and outer tine edges, the required mowing rate for lawn maintenance is easily met.

During lawn maintenance and punching processes, sand in the holes is unable to be completely removed, which often leads to local deformation of the lawn and bottom layer knots. JDY’s tines minimize the punching and actuality on the lawn, so that the sand volume removed is reduced, thus reducing customer operating costs.

Tine Specifications

JDY Solid Tines
JDY PN.	Length	Mount	Tip O.
JST1651906	165mm	19mm	6mm
JST1651908			8mm
JST1651910			10mm
JST1651912			12mm
JST1651914			14mm
JST1651916			16mm
JST1652206	165mm	22mm	6mm
JST1652208			8mm
JST1652210			10mm
JST1652212			12mm
JST1652214			14mm
JST1652216			16mm
JST1501906	150mm	19mm	6mm
JST1501908			8mm
JST1501910			10mm
JST1501912			12mm
JST1501914			14mm
JST1501916			16mm
JST1502206	150mm	22mm	6mm
JST1502208			8mm
JST1502210			10mm
JST1502212			12mm
JST1502214			14mm
JST1502216			16mm

Notes:

Tines can be customized according to your specific requirements.
