Mortise Lever Lock with Mortise Cylinder
Request a Quote
- Zhengshi Hardware mortise lever lock with mortise cylinder is designed with a brass cylinder and keys, suitable for applications with security requirements.
- Compared with other types of locks, this series of mortise locks have advantages in higher strength and better security.
- The surface treatment is performed by adopting Japanese advanced technology for better color adhesion and corrosion resistance. All tests are performed following Japanese JIS standards to ensure the durability of the locks from both appearance and structure.
- The options shown below are customized based on detailed requirements of customers. Welcome to contact us for your customized products!
Color
- Nickel plating
- Champagne gold
- Matte black
- Customized colors
MPD1614(KU)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(BA)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(EW)-X
- Lock case: POM
- Handle: Aluminum alloy, rosewood (The wood material can be customized)
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(NW)-X
- Lock case: POM
- Handle: Aluminum alloy, rosewood (The wood material can be customized)
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(GG)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(NS)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPD1614(XA)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 46mm
- Backset: 50mm
- Center distance of the mounting hole: 118mm
- Applicable door thickness: 33-42mm
MPF1614(KU)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(BA)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(EW)-X
- Lock case: POM
- Handle: Aluminum alloy, rosewood (The wood material can be customized)
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(NW)-X
- Lock case: POM
- Handle: Aluminum alloy, rosewood (The wood material can be customized)
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(GG)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(NS)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPF1614(XA)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-45mm
MPN1614(NT)-X
- Lock case: POM
- Handle: Aluminum alloy
- Bolt: POM and stainless steel
- Axe distance: 64mm
- Backset: 50mm
- Center distance of the mounting hole: 30mm
- Applicable door thickness: 33-42mm
