Push Pull Mortise Lock with Mortise Cylinder
Request a Quote
- Push pull mortise lock with mortise cylinder developed by Zhengshi Hardware is designed with a brass cylinder and keys, making it ideal for applications with security requirements.
- Compared with other types of push pull latches and locks, this series of push pull mortise locks have advantages in higher strength and better security.
- Japanese advanced technology is introduced for surface treatment. In addition, various tests are performed following Japanese JIS standard to guarantee the durability of the locks from both appearance and structure.
Color
- Nickel plating
- Champagne gold
- Matte black
- Customized colors
MG1814(ZY)-X
- Lock case: Galvanized zinc steel plate
- Lever handle: Aluminum alloy
- Bolt: POM and zinc alloy
- Axe distance: 72mm
- Backset: 55mm
- Center distance of the mounting hole: 38mm
- Door thickness: 33-50mm
MG2814(ZY)-X
- Lock case: POM
- Lever handle: Aluminum alloy
- Bolt: POM and zinc alloy
- Axe distance: 58mm
- Backset: 50mm
- Center distance of the mounting hole: 38mm
- Door thickness: 33-50mm
MG3814(ZF)-X
- Lock case: POM
- Lever handle: Aluminum alloy
- Bolt: POM and zinc alloy
- Axe distance: 28mm
- Backset: 55mm
- Center distance of the mounting hole: 38mm
- Door thickness: 33-50mm
Packaging and transportation
