Automatic Stripping and Blanking Machine
Request a Quote
(with Manipulator & Spinning Mould)
Features
- Single blanking and stripping unit, suitable for products in small plates or with well-organized patterns.
- High-precision linear screw motion guide and servo motor together with steady support base, ensuring stable, smooth and precise performance.
- Copper nozzle on the platform will help paper stack move steadily and avoid scratches and smears caused to products.
- Upper stripping plate can rotate 180 degrees, which is suitable for products with content not on the same page or with texts and pictures on the same page.
- Automatic lubrication system, timely maintenance for extended machine life.
- Manipulator is configured, labor is going to be saved and operation will be easier and safer.
- User-friendly interface.
- Customization services are provided.
Specifications
Machine model | |||
Max. paper size | 680 X 480 | 920 X 680 | 1080 X 780 |
Min. paper size | 400 X 300 | 550 X 400 | 650 X 450 |
Max. paper pile | 100 | 100 | 100 |
Min. paper pile | 40 | 40 | 40 |
Work bench | 850 | 850 | 850 |
Max. blanking size | 290x290 | 420x 420 | 450 x450 |
Min. blanking size | 30x30 | 30x 30 | 30x30 |
Blanking speed cycles/min | 15-22 | 15-22 | 15-22 |
Max. working pressure | 70 | 70 | 70 |
Air consumption L/min | 4 | 4 | 4 |
Overall power | 4.2kw/n, 380V | 4.2kw/n, 380V | 4.2kw/n, 380V |
Rotation | //// | 0-180 ° | 0-180 ° |
Manipulator grip range | 30-180 | 30-260 | 30-300 |
Manipulator grip load | 50-1200 | 50-1500 | 50-1800 |
Net weight | 1700 | 2200 | 2600 |
Gross weight | 1900 | 2500 | 3100 |
Machine net dimension | 2600x1400x1950 | 3100x1800x 1950 | 3600x2050x 1950 |
Packaging size | 2100x1500x2200 | 2700x1950x 2250 | 3100x2250x2250 |
At CBADEN, we supply an extensive range of converting & printing machines and provide comprehensive services to accommodate customer's individual production demands.
