High Pressure Oxygen Concentrator for Small Hospital

High Pressure Oxygen Concentrator for Small Hospital
High Pressure Oxygen Concentrator for Small Hospital
High Pressure Oxygen Concentrator for Small Hospital
High Pressure Oxygen Concentrator for Small Hospital
High Pressure Oxygen Concentrator for Small Hospital
High Pressure Oxygen Concentrator for Small Hospital
Request a Quote
Technical Parameters
Model JAY-10-4.0 JAY-15-4.0 JAY-20-4.0
Flow Rate 1-10L/min 1-15L/min 1-20L/min
Oxygen Purity 93% (±3%)
Outlet Pressure 20-60 PSI (0.14-0.4Mpa)
Sound Level ≤ 50dB ≤ 60dB
Net Weight 90kg 118kg
Power Consumption ≤ 1250W ≤ 2000W ≤ 2000W
Input Frequency 50Hz ; 60 Hz
Input Voltage AC 230V±10%
AC 110V ±10%
    Features
  • Thomas compressor
  • High efficiency three-tower adsorption system, more durable
  • Pressure gauge on site to adjust flexibly if necessary
  • Small and compact, easy to move for any emergency
  • Automatic dehydrator/refrigerated air dryer.
    Application
  • Connected with ventilator and anesthesia machine in ICU
  • Connected with ventilator and anesthesia machine in operating room
  • Connected with hyperbaric oxygen chamber
  • For hospital with 50-100 Beds
