CNC Tube Bending Machine
CNC Tube Bending Machine is mainly used to produce decorative metal tubes. Zhenhuan is able to provide a variety of swaging machines, such as twisting machine, tapering machine, rotary type swaging machine, tube spinning machine, tube bending machine, and so on.
We at Zhenhuan are a Chinese CNC tube bending machine supplier. Our products have the following features
- Three-axis numerical control, hydraulic clamping
- Gear and rack driving, each axis is equipped with high precision planetary reducer
- Tracking die is restored pneumatically
- CNC control, 12.1” touch screen operation, simple and easy
Technical Parameters
| Item | |||
| Max. bending angle | 190º | 190º | |
| Max. bending radius | 100mm | 150mm | |
| Max. tube length | 2000mm | 3000mm | |
| Max. tube wall thickness | 1.6mm | 2mm | |
| Max. tube diameter | Ф22mm | Ф40mm | |
| Productivity (second/curve) | 2s | 4-5s | |
| Axle speed | Feeding axle | 800mm/s | 600mm/s |
| Rotating axle | 180º/s | 90º/s | |
| Bending axle | 180º/s | 180º/s | |
| Axle accuracy | Feeding axle | ±0.2mm | ±0.5mm |
| Rotating axle | ±0.2º | ±0.2º | |
| Bending axle | ±0.5º | ±0.5º | |
| Axle power | Feeding axle | 0.75kW | 1.5kW |
| Rotating axle | 0.4kW | 0.75kW | |
| Bending axle | 1.5kW | 3.0kW | |
| Air source | 0.4-0.7MPa | - | |
| Hydraulic pressure | -(or 3.0-5.0MPa*) | 5.0-8.0MPa | |
| Power source | AC380V, 50Hz (or customized) | ||
| Dimension(L×W×H) | 2000×700×1500mm | 3200×800×1500mm | |
| Weight | 800kg | 1800kg | |
Note: The product of JXWGJ-22 series can be driven by pneumatic or hydraulic system, and JXWGJ-40 is driven hydraulic system, only.
Give us your maximum tube diameter, wall thickness, shape, etc., and we provide you with the exact tube bending machine!
