To better serve our clients, Changcheng also provides a complete series of strapping consumables and accessories, including strapping seals, paper edge protectors, plastic edge protectors, wire strapping buckles and brick edge protectors. There are more choices to optimize the packaging performance.

Strapping Seals / Serrated Seals

Open seals for PET strapping

Changcheng’s strapping seals for PET strapping are manufactured from high-quality galvanized steel and thus they are high-strength and durable. They are usually used for PET strapping and manual strapping in fields of the ceramic industry, stone industry, the artificial board industry, the solar PV industry, fruits and bricks transportation.

Model LxWxT Weight Number of seal/kg PET strap width
Metal seal 1308 30x15.5x0.8mm 6.4 156 11-13mm
Metal seal 1608 30x19.2x0.8mm 7.6 131 15-16mm
Metal seal 1610 30x19.2x1mm 9.5 105 15-16mm
Metal seal 1908 32x22.3x0.8mm 9.5 105 19mm
Cardboard Edge Protector / Angle Board

Paper edge protectors, as known as paper angles, paper angle protectors, corner protectors and angle protectors, are made by gluing multiple layers of paper or cardboard together and used to enhance the strength of packages and protect edges or corners.

Changcheng’s paper edge protectors have smooth surface without any irregularity. Versatile paper edge protectors provide strong protection to inside and outside of packages.

The design of paper edge protectors embodies Changcheng’s idea of being green and environment-friendly. They can be recycled and reused and particularly suitable for products that only need edge or corner protection, which saves energy and protects the environment.


Advantages

Changcheng’s paper edge protectors are lightweight, durable, stable, damp-proof and pressure-resistant. They can provide support as a buffer against pressure. Used along with straps (or films), Changcheng’s paper edge protectors can be used to pack separated cartons, planks, metal tubs and electronic components as a whole and prevent them from tiling or collapsing.


Highlights
  • Paper edge protectors can protect edges or corners of products packed with pallets to prevent damage to products during loading, transportation and handling;
  • They are easy to be removed as it only needs cutting straps or films;
  • Paper edge protectors of various sizes meet your needs. For example, paper edge protectors that are 3mm in thickness can be used to protect product surface. Corner edge protectors in small sizes can be used to prevent corners or edges from tight strapping damage, which saves packaging costs;
  • They can provide strong support to pile up cartons;
  • They can be recycled and reused. Since they are made by gluing multiple layers of cardboard or paper together, they can be recycled and reused;
  • They are free from fumigation when they are exported, which saves transportation costs.
Functions

Paper edge protectors are widely used to protect goods during transportation and they are the ideal packaging product since they are lightweight, durable and strong enough to prevent damages to goods. To meet different needs of transportation methods and environment, paper edge protectors can be used to:

  • Prevent outside damage; paper edge protectors can be used to protect corners and edges of products during cross-border transportation and thus reduce the cost of in-transit damage.
  • Pack products as a whole; paper edge protectors can be placed at every corner of separated cartons, planks or metal tubs to package them up as a whole with the use of strap.
  • Enable piling up cartons; as each paper edge protector can stand pressure up to 1,500 kg, they can be used to enable piling up cartons during the transportation of washing machines, microwave ovens and refrigerators to avoid in-transit damages.

Different types of paper edge protectors

Changcheng provides different types of paper edge protectors, including L-shaped edge protectors, U-shaped edge protectors, L-shaped paper edge protectors, corner protectors with a puzzle joint, waterproof edge protectors, corner edge protectors (90 degree) and special corner protectors.

  • Corner protectors with a puzzle joint

    Used to protect corners of package with paper edge protectors

  • Outer diameter protector

    Used to protect the circumference of cylindrical products against damages

  • L-shaped paper edge protector

    Used to enhance strength and stability of products and protect product corners

  • U-shaped paper edge protector

Applications

Paper edge protectors are widely used in various products transportation, including construction materials, aluminum, steels and other metals, bricks, candies, frozen food, daily necessities, home appliances, chemicals, drugs, computers and high-tech products.

  • Cylindrical products
  • Construction materials
  • Home appliances
  • Medical products
  • Planks
  • Ceramic tiles
  • Expensive fruits
Changcheng’s advantages

Changcheng mainly manufactures open and closed brown paper edge protectors and produces protectors in customized colors if there is a large volume of orders. Changcheng’s paper edge protectors meet the criteria of ISO9001 and pass the RoHS lab tests to enter the international market.

We can produce paper edge protectors that are 20 to 100mm in width and 1 to 10mm in thickness. L-shaped edge protectors, U-shaped edge protectors, outer diameter protectors, corner protectors with a puzzle joint, corner edge protectors (90 degree) and special corner protectors are provided to meet different packaging needs.

Specifications

30x30x3mm, 40x40x3mm, 40x40x4mm, 40x40x5mm, 45x45x3mm, 45x45x4mm, 45x45x7mm, 50x50x4mm, 50x50x5mm, 80x80x4mm, 80x80x5mm, 80x80x7mm

Tags
  • pallet protection products
  • pallet corners
  • pallet edge protector
Plastic Corner Protectors

Plastic corner protectors are placed between an edge of products and straps to protect products and straps against damages in case that edges of some products are vulnerable to tight strapping or straps would be cut off by sharp edges of products. Plastic corner protectors are mainly used in the fields of artificial boards, stone, ceramic tiles and PV modules.

Changcheng provides high-quality plastic corner protectors to better safeguard product transportation.


Applications
  • Timber packing / plywood packing / fiber board packing
  • Solar PV module packing
Stone packing
Model No For strap width LxWxT Piece weight Material & Packing Quantity
Plas corner 19 ≤19mm 35x25x2.5mm 8.7g PVC,115pcs/kg,20kg/bag
Plas corner25 ≤25mm 50x30x3.8mm 18.2g PVC,55pcs/kg,20kg/bag
Plas corner32 ≤32mm 50x30x3mm 20g PVC,50pcs/kg,20kg/bag
Plas corner 32P ≤32mm 58x30x3mm 16.5g PC,83pcs/kg,20kg/bag
Wire Strapping Buckles

Changcheng’s wire buckles made of high-quality steel wires have strong tensioning capacity after galvanization and phophorization surface treatment. They are particularly designed for PP straps and PET straps, such as, woven straps and flexible straps.

Changcheng’s wire buckles enjoy the following advantages:
  • Easy to use with strap tensioners;
  • Used to tightening large products, such as, aluminum ingots, steels and stone, on pallets and handcarts or in containers;
  • Strong enough to reach 4.5 tons of tensioning force
  • Applicable to various types of PP straps and PET straps, such as, webbing straps and flexible straps

Applications
  • Containers, large machines, large pieces of glass, tubes, oil drums, steels, woods, paper and chemicals
  • Changcheng’s wire buckles optimize packaging efficiency and save costs.
  • Raw material: steel wire
  • Surface treatment: galvanization, phosphorization and bluing
Specifications
Products Types Model no. Width Wire dia. Applicable strap width Tensioning capacity Pcs/carton Surface treatment
Wire buckles Galvanized wire buckles JCL1333G 13mm 3.3mm 13mm (flexible strap) 480kg 1000 Galvanization
JCL1635G 16mm 3.5mm 16mm (flexible strap) 680kg 1000 Galvanization
JCL1940G 19mm 4.0mm 19mm (flexible strap) 950kg 1000 Galvanization
JCL1943P 19mm 4.3mm 19mm (flexible strap) 1000kg 1000 Galvanization
JCL1945P 19mm 4.5mm 19mm (flexible strap) 1100kg 1000 Galvanization
JCL2550G 25mm 5.0mm 25mm (flexible strap) 1250kg 500 Galvanization
JCL2560G 25mm 6.0mm 25mm (flexible strap) 1600kg 500 Galvanization
JCL3260G 32mm 6.0mm 32mm (flexible strap) 2500kg 250 Galvanization
JCL3270G 32mm 7.0mm 32mm (flexible strap) 2500kg 250 Galvanization
JCL3870G 38mm 7.0mm 38mm (woven straps) 3200kg 200 Galvanization
JCL4080G 40mm 8.0mm 40mm (woven straps) 3800kg 150 Galvanization
JCL5080G 50mm 8.0mm 50mm (woven straps) 4000g 150 Galvanization
Phosphorized wire buckles JCL1333P 13mm 3.3mm 13mm (flexible strap) 480kg 1000 Phosphorization
JCL1635P 16mm 3.5mm 16mm (flexible strap) 680kg 1000 Phosphorization
JCL1940P 19mm 4.0mm 19mm (flexible strap) 950kg 1000 Phosphorization
JCL1943P 19mm 4.3mm 19mm (flexible strap) 1000kg 1000 Phosphorization
JCL1945P 19mm 4.5mm 19mm (flexible strap) 1100kg 1000 Phosphorization
JCL2550P 25mm 5.0mm 25mm (flexible strap) 1250kg 500 Phosphorization
JCL2560P 25mm 6.0mm 25mm (flexible strap) 1600kg 500 Phosphorization
JCL3260P 32mm 6.0mm 32mm (flexible strap) 2500kg 250 Phosphorization
JCL3270P 32mm 7.0mm 32mm (flexible strap) 2500kg 250 Phosphorization
JCL3870P 38mm 7.0mm 38mm (flexible strap) 3200kg 200 Phosphorization
JCL4080P 40mm 8.0mm 40mm (woven straps) 3800kg 150 Phosphorization
JCL5080P 50mm 8.0mm 50mm (woven straps) 4000kg 150 Phosphorization
Brick Edge Protectors

Changcheng provides brick edge protectors that are particularly designed to protect the straps from sharp edges of bricks and efficiently pack bricks together along with straps.

Changcheng’s brick edge protectors are high-quality, flexible, resilient and economic. Nowadays, they are the most suitable edge protectors for brick packaging and transportation.

We produce brick edge protectors that are 45mm in width and 0.45 in thickness. They weigh 9 to 10 kg per coil.
