Mechanical Seals for Glass-Lined Equipment
Here at Taiji, we offer four types of mechanical seals for glass-lined equipment, namely 212 type, 212F type, 2009 type and 2017B type. These mechanical seals ensure safe containment of the corrosive medium and keep the pressure inside your reactors unchanged. With years of experience in designing mechanical sealing solutions, we offer trusted solution for protecting operators, reactors and the environment.
212 Type Single Mechanical Seal
Pressure: -0.1~0.4MPa
Temperature: -20~200℃
Rotating Speed: ≤2m/s
Characteristics: The agitator shaft seal comes with simple structure, small installation space and ease of cleaning and maintenance; it is suitable for various particle-free medium with strong corrosion.
212F Type Dry Single Mechanical Seal
Pressure: -0.1~0.2MPa
Temperature: -20~120℃
Rotating Speed: ≤2m/s
Characteristics: This is a dry running mechanical seal with no need of lubrication. It comes with a detachable dust-proof cover that is made of organic glass, and is easy to clean. All parts in contact with the medium are made from highly corrosion resistant nonmetallic material, suitable for various highly corrosive medium except crystalline and hydrofluoric acid.
2009 Type Double Mechanical Seal
Pressure: -0.1~1.0MPa
Temperature: -20~200℃
Rotating Speed: ≤2m/s
Characteristics: Integrated structure, directionless drive; suitable for all kinds of highly corrosive mediums with granules.
2017B Type Dry Double Mechanical Seal
Pressure: -0.1~1.0MPa
Temperature: -20~200℃
Rotating Speed: ≤2m/s
Characteristics: Dry-running mechanical seal without lubrication; integrated structure, high running efficiency and long service life; perfect for reactors processing highly corrosive mediums with granules.
Product Gallery
