UL FM Wafer Type Butterfly Valve with Tamper Switch
Request a Quote
Working Pressure: 175PSI,200PSI,250PSI,300PSI are available upon request
Connection Ends: ASME Class 125 & 150
Stem drive by keys, parallel or diagonal square or flat head
Temperature Range: 0 – 80 Degree
Coating: Fusion Bonded Epoxy Coating in accordance with ANSI/AWWA C550
FM Approved & UL/ULC Listed
Part | Specification |
1.Valve Body | ASTM A536,65-45-12 |
2.Seat | EPDM & Backing |
3.Disc | ASTM A536,65-45-12 |
4.Stem | AISI 420,One-Piece Stem Design |
5.O-Ring | NBR |
6.Bushing | PTFE |
7.Signal Gear Box | ASTM A536,65-45-12 |
Size(mm) | A | B | M | H | H1 | H2 | H3 | K | G | ¢D | C | ¢2 | L | |
Inch | mm | |||||||||||||
2 | 50 | 140.5 | 64.5 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 53.9 | 43 | 14 | 32 |
2.5 | 65 | 153 | 72 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 65.2 | 46 | 14 | 32 |
3 | 80 | 157.5 | 86 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 79.7 | 46 | 14 | 32 |
4 | 100 | 176 | 100 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 105 | 52 | 16 | 32 |
5 | 125 | 191 | 112 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 130 | 56 | 16 | 32 |
6 | 150 | 202.5 | 128 | 200 | 305 | 234 | 69 | 115 | 90 | 62.5 | 158 | 56 | 20 | 32 |
8 | 200 | 243.5 | 162 | 250 | 303 | 225 | 73 | 120 | 125 | 77.5 | 207 | 60 | 26 | 45 |
10 | 250 | 273 | 194 | 250 | 303 | 225 | 73 | 120 | 125 | 77.5 | 253.3 | 68 | 26 | 45 |
12 | 300 | 311 | 223 | 250 | 303 | 225 | 73 | 120 | 125 | 77.5 | 301.9 | 78 | 28 | 45 |
