CPH Hot Water Circulation Pump

CPH Hot Water Circulation Pump
CPH Hot Water Circulation Pump
Request a Quote
Performance Range

Max. Flow: 36m3/h
Max. Head: 30m

Application Limits
  • Suction head up to 7m
  • Liquid temperature up to +100℃
  • Ambient temperature up to +40℃
  • Max. Working pressure: 6bar
  • Voltage fluctuation should not exceed 10% of rated value.
  • pH: 6.5 to 8.5
  • Mains connection: 220V/50Hz, 380V/50Hz
Certificate
Applications Fields
  • Suitable for transferring water without abrasive particles or other liquid whose properties are similar to water.
  • Widely used in HVAC, industrial circulating water system, solar hot water and boiler circulating system, living water supply, etc.
Features
  • Pump body: Cast iron, electrophoretic treatment
  • Impeller: Cast iron, electrophoretic treatment
  • Shaft: 304 stainless steel welding shaft
  • Mechanical seal: SiC/Graphite/ FPM rubber
  • Motor: 2 pole asynchronous motor, copper wires, built-in thermal protector, fully closed fan cooling, continuous running
  • Protection: IP44
  • Insulation: B
  • NSK bearing
Performance Curve
