Underground Drilling Rig, Type ZLJ-650

Request a Quote

View All: http://cgeg-exploration.com/4-5-underground-drilling-rig.html

Introductions

ZLJ-650 underground drilling rig, mainly using alloy bit, is suitable for the coal mine tunnel engineering drilling and coalfield underground exploration drilling. It has the features of light weight, small size, good disassembly performance and large installed power. There are two optional drilling depths: 20m and 100m.

Parameters

Basic Parameters	Drilling Depth	100m		20m
	Borehole Diameter	Φ75mm		Φ150mm
	Drill Rod Diameter	Match with borehole
Power Unit Parameters		Gear 1	Gear 2		Gear 3
	Output Rotation Speed (Forward)	94r/min	230r/min		365r/min
	Rated Maximum Output Torque		650N·m
	Vertical Feed Stroke		400mm
Main Winch Parameters	Hoisting Capacity( Single Rope, First Floor)	10KN
	Maximum Single Rope Hoisting Speed	1.944m/min
	Rope Diameter	9.3mm
	Rope Capacity	18m
Power Parameters	Motor Model	YBK2-132M-4
	Power	7.5KW
	Rotation Speed	1450r/min

Features

ZLJ-650 drilling rig has 3 gears of rotation speed and torque is larger at low speed, so it has wide applications.
It has long vertical feed stroke of 400mm, which is helpful to increase drilling efficiency and reduce drill plugging and drill burning accidents.
Drilling is smooth and stable and fixing is simple. High-speed drilling has good stability.
Drilling pressure gauge and hydraulic pressure gauge are combined together and oil shockproof structure is adopted. This gauge has simple drilling pressure graduation, accurate indication and long service life.
It has less control handles and the operation is flexible and reliable.
ZLJ-650 drilling rig is designed with advanced structure and rational layout and it's convenient for maintenance and repair.
ZLJ-650 drilling rig has small size, light weight and good dismountability so that it's convenient for moving and transporting.
