Hydraulic Shear
This hydraulic shear is installed with a motor-drive back gauge device with manual fine-adjusting, numerical displayed. A synchronous pneumatic loading car is for your choice.
Features
- The frame is welded with sufficient strength and rigidity
- This hydraulic shear is equipped with a mechanism for quick adjusting blade clearance
- This hydraulic shear is equipped with a shadow light device ensuring cutting operation.
- A sensitive and reliable safety barrier is equipped on this hydraulic shear.
As a forming machine manufacturer and supplier in China, Zhenhuan can provide high quality roll forming machine, spiral duct forming machine, plasma cutting machine, welding machine and other forming machines for our global customers.
Technical Parameters
| Code | Thickness | Width | Angle | Number of Stroke | Backguage Range | Motor Power | Weight | Overall Dimensions |
| mm | mm | ° | min-1 | mm | kW | kg | mm(L×W×H) | |
| 4×2000 | 4 | 2000 | 1°30′ | 22 | 20~500 | 4 | 2900 | 2660×1380×1480 |
| 4×2500 | 4 | 2500 | 1°30′ | 20 | 20~500 | 4 | 3500 | 3110×1500×1450 |
| 4×3200 | 4 | 3200 | 1°30′ | 18 | 20~500 | 5.5 | 5500 | 3840×1685×1620 |
| 4×4000 | 4 | 4000 | 1°30′ | 15 | 20~500 | 5.5 | 7000 | 4640×1850×1700 |
| 6×2500 | 6 | 2500 | 1°30′ | 18 | 20~500 | 7.5 | 6200 | 3130×1530×1600 |
| 6×3200 | 6 | 3200 | 1°30′ | 15 | 20~500 | 7.5 | 7200 | 3840×1675×1620 |
| 6×4000 | 6 | 4000 | 1°30′ | 14 | 20~500 | 7.5 | 8000 | 4630×1800×1620 |
| 6×5000 | 6 | 5000 | 1°30′ | 8 | 20~500 | 11 | 11000 | 5770×2380×2255 |
| 6×6000 | 6 | 6000 | 1°30′ | 7 | 20~800 | 11 | 15000 | 6810×2530×3250 |
| 8×2500 | 8 | 2500 | 1°30′ | 10 | 20~500 | 11 | 6800 | 3140×1665×1620 |
| 8×3200 | 8 | 3200 | 1°30′ | 9 | 20~500 | 11 | 8100 | 3587×1800×1650 |
| 8×4000 | 8 | 4000 | 1°30′ | 8 | 20~600 | 11 | 9000 | 4667×1910×1650 |
| 8×5000 | 8 | 5000 | 1°30′ | 7 | 20~600 | 18.5 | 14000 | 5612×2600×2350 |
| 10×2500 | 10 | 2500 | 1°30′ | 10 | 20~600 | 11 | 8800 | 3200×1850×1760 |
| 10×3200 | 10 | 3200 | 1°30′ | 10 | 20~600 | 11 | 9500 | 3900×1900×1760 |
| 12×2500 | 12 | 2500 | 2° | 9 | 20~800 | 18.5 | 9000 | 3210×1920×1850 |
| 12×3200 | 12 | 3200 | 2° | 8 | 20~800 | 18.5 | 10500 | 3910×2040×1920 |
| 12×4000 | 12 | 4000 | 2° | 7 | 20~800 | 18.5 | 12600 | 4725×2000×2040 |
| 12×5000 | 12 | 5000 | 2° | 8 | 20~800 | 22 | 15500 | 5750×2260×2240 |
| 16×2500 | 16 | 2500 | 2°30′ | 8 | 20~600 | 22 | 10600 | 3300×2150×1880 |
| 16×3200 | 16 | 3200 | 2°30′ | 8 | 20~600 | 22 | 12500 | 4105×2325×2220 |
| 16×4000 | 16 | 4000 | 2°30′ | 7 | 20~600 | 22 | 15500 | 4905×2385×2250 |
| 20×2500 | 20 | 2500 | 2°30′ | 6 | 20~600 | 30 | 13500 | 3400×2350×2700 |
| 20×3200 | 20 | 3200 | 2°30′ | 5 | 20~800 | 30 | 17000 | 4100×2350×2730 |
| 20×4000 | 20 | 2500 | 2°30′ | 5 | 20~800 | 30 | 21000 | 4900×2350×2760 |
| 25×2500 | 25 | 3200 | 3° | 5 | 20~800 | 30 | 16500 | 3480×2410×2750 |
| 25×3200 | 25 | 4000 | 3° | 5 | 20~800 | 37 | 20500 | 4180×2410×2690 |
| 32×2500 | 32 | 2500 | 3°30′ | 4 | 20~800 | 45 | 22000 | 3300×3450×3200 |
