8112 Wrench

8112 Wrench
Request a Quote

The code No.8112 stainless steel single box wrench is used to tighten or loosen bolts and nuts. It is made of stainless steel processed by drop forging.

304QF stainless steel tools technical parameters:
Chemical composition: %
C Si Mn Cr Ni S P N
≤0.08 ≤0.85 ≤1.8 18.0-20 8.0-10.5 ≤0.03 ≤0.045 ≤0.2
Physical property
  • Tensile strength: σb(MPa)≥520
  • Tensile strength: σb(MPa)≥520
  • Offset yield strength:σ0.2(MPa)≥205
  • Elongation:δ5(%)≥40
  • Contraction percentage of area: z(%)=60
  • Density (20℃, g/cm3): 7.93
  • Hardness: HRC15-25
  • Melting point (℃): 1398~1454
  • Specific heat (0~100℃, KJ·kg-1K-1): 0.50
  • Heat conductivity (W·m-1·K-1): (100℃) 16.3, (500℃) 21.5
  • Linear expansion coefficient (10-6·K-1): (0~100℃) 17.2; (0~500℃) 18.4
  • Resistivity (20℃, 10-6Ω·m): 0.73
  • Magnetism: ≤5nT within 10cm in the magnetic field

2. Martensitic stainless steel (cutting tools stainless steel): representative grade: 420
The mechanical property of martensitic stainless steel is adjustable by heat treatment. Generally speaking, it is a type of hardenable stainless steel. It is hardened after quenching. Different tempering temperatures give different combinations of hardness and toughness. This stainless steel is widely used in such industries where the requirements of corrosion resistance is not very high, plus the cutting tools and machine elements have high requirements on strength.

420 stainless steel tools parameters:
Chemical composition: %
C Si Mn Cr Ni S P
0.16-0.25 ≤1.00 ≤1.00 12.0-14.0 ≤0.75 ≤0.03 ≤0.04
Physical property
  • Tensile strength: σb(MPa)≥365
  • Offset yield strength:σ0.2(MPa)≥440
  • Elongation:δ5(%)≥20
  • Contraction percentage of area: z(%)=50
  • Density (20℃, g/cm3): 7.75
  • Hardness: HRC35-45
  • Melting point (℃): 1427
  • Specific heat (25℃, J·kg-1K-1): 460
  • Heat conductivity (W·m-1·K-1): 24.9
  • Linear expansion coefficient (mm/℃): (at20-100℃)
Parameters:
Number S (mm) L (mm) Weight (g)
8112-14 14 270 145
8112-17 17 310 200
8112-19 19 330 250
8112-22 22 350 320
8112-24 24 370 400
8112-27 27 400 500
8112-30 30 430 730
8112-32 32 430 700
8112-36 36 460 900
8112-41 41 490 1090
8112-46 46 520 1560
