High-Flow Pleated Filter Element, PH Series

High-Flow Pleated Filter Element, PH Series
Request a Quote

Replacement filter

The high-flow pleated filter element generally adopts deep fine polypropylene, polyester, PTFE or glass fiber membrane as the filter material, with the flow rate up to 1300L/min. Due to its composite folding of multiple layers of filtration material and the design of multi-layer gradient precision filtration, it has a much high dirt and dust holding capacity, making it the best choice for industrial water treatment.

Dimensions
End cap outer diameter (mm) 10
End cap inner diameter (mm) 80
Length (") 40
Material of Components
  • Filter material: PP, PES, PTFE, GF
  • End cap: PP
  • Sealing gasket: NBR or silicone rubber
  • Inner support: PP
  • Outer support: PP
Features
  • High rejection rate and large dirt holding capacity
  • High removal rate for particles, colloids
  • High flow and low water pressure drop
  • Filtration precision can easily be adjusted
Applicable Conditions
  • Maximum operating temperature:100oC
  • Maximum operating pressure difference: 0.25 MPa
  • Suggested pressure difference for replacement: 0.22 MPa
  • Nominal micro rating: 5-20µm
Applications
  • PCB ultra pure water, deionized water
  • Petroleum chemical, organic solvents, ink filtration
  • Metal cutting fluid, electroplating solution, pharmaceutical industry
  • Food & beverage, oilfield injection water filtration
