Pleated Pool & SPA Filter, PS Series

Request a Quote

View All: http://waterfilter-system.com/5-16-pleated-pool-spa-filter.html

Replacement filter cartridge

This pleated filter cartridge is fabricated by folding antibacterial polyester fiber material into multiple layers. The replacement filter can have either the end caps made of PP material or the soft end caps that are AB cured. The pleated filter possesses excellent mechanical strength, light resistance, and high-temperature resistance. Furthermore, the filter cartridge can be reused through regular cleaning, thereby reducing both the frequency of replacement and the total usage cost.

Dimensions

End cap outer diameter (mm)	143	66	90	115	143
End cap inner diameter (mm)	16	28	30	50	50
Length (")	9.75	10	100	80	253

Material of Components

Filter material: PP, polyester film
End cap: PP, PO
Sealing gasket: NBR or silicone rubber
Inner support: PE

Features

High rejection rate and large dirt holding capacity
High flow and low water pressure drop
Can easily be cleaned for reuse

Applicable Conditions

Water temperature: 3-45℃
Inlet water pressure: 0.1-0.6 MPa
Nominal micro rating: 5-20µm

Applications

Home swimming pool
Public swimming pool
Children SPA water circulation
