Feature
The friction stir welding machine has the following feature

1. It adopts small gantry structure with high rigidity and good cost performance.
2. This welding machine adopts dimensional surface parallel welding: 0-12mm; micro welding: 0.2-1.2mm.
3. There is optional parallel welding.
4. The drive system of the lathe has the following advantages: simple structure, high driving precision and fast speed.
5. The lathe has high rigidity and good vibration resistance.
6. Humanization designed control system has extremely high stability.
7. The structure of electrical spindle head occupies less space.
8. It adopts wireless hand wheel which can prevent wire intertwist.

Description
The friction stir welding is a solid-phase jointing technique. During the friction stir welding, a special cylindrical shaft shoulder and the pin-convex rotation head are rotated and inserted into the workpiece to be welded. The friction between the rotation head and the material to be welded will generate friction heat which can heat plastify the material. When the rotary unit goes forward along the side to be welded, the heat plastified material travels from the front of the rotation head to the back side, thus realizing solid-phase jointing between the work pieces by the assistance of of the machine forging.

Finished products
Parameters of different product models
1. HMC1006 Friction Stir Welding Machine
MODEL HMC1006
STRUCTURE TYPE GANTRY
MAX WELDING THICKNESS ALUMINUM,12mm
STROKE IN X AXIS 0-600mm
STROKE IN Y AXIS 0-1000mm
STROKE IN Z AXIS 0-250mm
EXTERNAL SIZE OF MAIN PART 2500mm×2500mm×2300mm (L×W×H)
EXTERNAL SIZE OF WORK TABLE 600mm×1000mm(L×W)
WORKING SPEED IN X AXIS 0-3000 mm/min
WORKING SPEED IN Y AXIS 0-3000 mm/min
WORKING SPEED IN Z AXIS 0-2000 mm/min
SWING AXIS(A AXIS) 0-5°Manual
CNC CONTROLLER Fagor8055,Siemens 828D(dependent on customer choice)
2. HMC1510 Friction Stir Welding Machine
MODEL HMC1510
STRUCTURE TYPE Vertical static gantry
MAX WELDING THICKNESS Aluminum 40mm, copper alloy 20mm,May alloy 40mm
STROKE IN X AXIS 0-1500mm
STROKE IN Y AXIS 0-1000mm
STROKE IN Z AXIS 0-450mm
EXTERNAL SIZE OF MAIN PART 4400mm×2400mm×3550mm (L×W×H)
EXTERNAL SIZE OF WORK TABLE 1500mm×1000mm(L×W)
WORKING SPEED IN X AXIS 0-6000 mm/min
WORKING SPEED IN Y AXIS 0-6000 mm/min
WORKING SPEED IN Z AXIS 0-3000 mm/min
ROTATION AXIS(C AXIS) n×360°CNC control
SWING AXIS(A AXIS) 0-5°Manual
CNC CONTROLLER Fagor8055,Siemens 828D(dependent on customer choice)
3. HMC2510-2D Friction Stir Welding Machine
MODEL HMC2510-2D
STRUCTURE TYPE GANTRY
MAX WELDING THICKNESS Aluminum 40mm, copper alloy 20mm,May alloy 40mm
STROKE IN X AXIS 0-2500mm
STROKE IN Y AXIS 0-1000mm
STROKE IN Z AXIS 0-450mm
EXTERNAL SIZE OF MAIN PART 6600mm×2400mm×3550mm (L×W×H)
EXTERNAL SIZE OF WORK TABLE 2500mm×1000mm(L×W)
WORKING SPEED IN X AXIS 0-6000 mm/min
WORKING SPEED IN Y AXIS 0-6000 mm/min
WORKING SPEED IN Z AXIS 0-3000 mm/min
SWING AXIS(A AXIS) 0-5° Manual
CNC CONTROLLER Fagor8055,Siemens 828D(dependent on customer choice)
4. HMC4020-3D Friction Stir Welding Machine
MODEL HMC4020-3D
STRUCTURE TYPE Vertical static gantry
MAX WELDING THICKNESS Aluminum 40mm, copper alloy 20mm,May alloy 40mm
STROKE IN X AXIS 0-4000mm
STROKE IN Y AXIS 0-1850mm
STROKE IN Z AXIS 0-1000mm
EXTERNAL SIZE OF MAIN PART 10700mm×4000mm×5660mm (L×W×H)
EXTERNAL SIZE OF WORK TABLE 4000mm×2000mm(L×W)
WORKING SPEED IN X AXIS 0-6000 mm/min
WORKING SPEED IN Y AXIS 0-6000 mm/min
WORKING SPEED IN Z AXIS 0-3000 mm/min
ROTATION AXIS(C AXIS) n×360°CNC control
RETURN AXIS(A AXIS) 0-5°Manual
CNC CONTROLLER Fagor8055,Siemens 828D(dependent on customer choice)
Principle

Jinfeng introduction
Jinfeng has 2 large specified accessory warehouse with sufficient stock, so that we can provide service in time.
Jinfeng Welding & Cutting Machinery Manufacture Co., Ltd hires senior engineers from ESAB to lead mechanical department, electrical department and software department. There are 80 people in the team in total. They will carry out development and design of various structural steel H beam production lines, so that we have technical guarantee.

Jinfeng has strong production capacity: we have 13 imported CNC machining centers, 3 4mx12m large machining centers and 300 equipment sets such as CNC grinding machine, drilling machine and milling machine etc. We also have specified hardware processing workshop, plate welding workshop, assembly shop, packaging shop, painting and drying shop etc.

We have a stable sales team. All the members of the sales team have more than 10 years of experience in service, so that they can provide customers with various consultation and services rapidly, in time and expertly. Our executive vice president leads an after-sales service team of 30 employees, so that they can provide 24-hour after-sales service all year round.
