Stainless Steel Fermentation Tank

Weiying stainless steel fermentation tank is a cell culture device that applies standard mechanical agitation system. Due to its systematic design and distinctive structure, the stainless steel fermentation tank offers unparalleled benefits that are tailored to your individual needs.

Tank system
  • Tank material: stainless steel S31603 or S30408
  • Tank design pressure: 0.3MPa
  • Jacket design pressure: 0.35MPa
  • Tank structure: fermentation tank (sampling), discharging valve, standard temperature/PH/DO sensor socket
  • Tank lid structure: 1 foam electrode socket, 1 light mirror, 3 common charging inlets, 1 air vent
  • Surface treatment: stainless steel internal and external polishing to mirror finish, polishing accuracy Ra0.4
Sterilization method
  • In-situ steam sterilization;
Stirring system
  • Standard type blades are specially used for fermentation
  • Control range: 50-300rpm
  • Control accuracy: ± 1%
Temperature control
  • Cooling water temperature: 5~65℃
  • Temperature control accuracy: ±0.1℃
pH control
  • Mettler Toledo pH electrodes and shielded cables
  • pH range: 2~12pH
  • pH control accuracy: ±0.02pH
Dissolved oxygen control
  • Mettler Toledo DO electrodes and shielded cables
  • Range: 5~100%
  • Control accuracy: ±2%
Foam control
  • Automatic detection of foam to add defoamer
  • Sensitivity 100-100000
Charging control
  • Automatic peristaltic pump
  • Range: 0-5L / min,
  • Control accuracy; ± 2%
Air flow control
  • Manually operated adjustment
  • Range: 0-5000L/min
Complete Biological Fermentation and Cell Culture Equipment
  • Stirring method: standard mechanical agitation system
  • Nominal capacity: 100L~50000L;
  • Height to diameter ratio: H: D=2.0-3.0;
  • Charging factor: 0.7;
  • Sterilization form: in-situ sterilization;
  • System configuration: general three-tiered fermentation;
  • System parameter control: three-tiered fermentation control is available, which is individually adapted to the customer’s needs;
  • Auxiliary system: seed tank, fermentation tank, control system, air filtration system, pipes and valves, utilities, etc.;
Technical Data
Model 100L 200 500 1000 2000 5000 10000 20000
Diameter (mm) 400 500 700 900 1200 1500 5250 6550
Height (mm) 2000 2300 2650 2900 3800 4480 5250 6550
Numbers of agitators 1 1 2 3 3 4 4 4
Agitator speed (r/min) 20-300
Motor power (kW) 0.55 0.75 1.1 1.5 3 5.5 7.5 7.5
Jacket pressure (MPa) 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
Inner working pressure (MPa) 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2

Weiying is a company dedicated to providing custom engineered filtration and drying equipment for the pharmaceutical, chemical, fine chemical and food industries.
