Studio Microphone
Description
The low noise circuitry of the studio microphone is symmetrical and transformer-less, resulting in exceptional transient response and clean output even under high-output conditions. Used on vocals, drum overheads, woodwind sections, and guitar cabinets as well as on-air announcing, the studio microphone is a microphone of many talents, and is as useful on a live stage and broadcast facility as it is in the recording studio.
Technical Specifications of the Studio Microphone
| Model No. | HT-320F | HT-66 | HT-68 | HT-69 | HT-69A |
| Capsule Type | Condenser | Condenser | Condenser | Condenser | Condenser |
| Frequency Response | 20Hz-20kHz | 20Hz-20kHz | 30Hz-18kHz | 30Hz-18kHz | 30Hz-18kHz |
| Polar Pattern | Hypercardioid | Hypercardioid | Hypercardioid | Uni-Directional | Uni-Directional |
| Output Impedance (Ohm) | 75 | 75 | 75 | 75 | 75 |
| Sensitivity (±2dB) | -40dB | -38dB | -40dB | -40dB | -40dB |
| Power Supply | Phantom Power 48V | Phantom Power 48V | Phantom Power 48V | Phantom Power 48V | Phantom Power 48V |
| N.W. | 0.11kg | 0.33kg | 0.33kg | 0.33kg | 0.33kg |
| Sound Pick-up Distance | 3m | 1m | 1m | 1m | 1m |
| Dimension (mm) | Diameter 30 Length 170 | Diameter 45 Length 200 | Diameter 45 Length 200 | Diameter 45 Length 200 | Diameter 45 Length 200 |
| Output | Balance | Balance | Balance | Balance | Balance |
As a professional studio microphone manufacturer and supplier based in China, our company not only provides microphone, but also supplies wireless microphone system, IR language distribution system, conference system, and much more.
