High Speed Cut- to- length Line
This high speed cut-to-length line consists of hydraulic loading car, double-head uncoiler, pre-leveler, fine-leveler, length gauge, shear, stacker, etc. It is used to cut the cold rolled coils into sheets in certain length.
Technical Data
| Model | T44QK- | T44QK- | T44QK- | T44QK- |
| Code | 2×1300 | 2×1600 | 3×1300 | 3×1600 |
| Coil thickness(mm) | 0.3-2 | 0.3-2 | 0.3-3 | 0.3-3 |
| Coil width(mm) | 800-1300 | 800-1600 | 800-1300 | 800-1600 |
| Cutting length range(mm) | 10.0-9999 | 10.0-9999 | 10.0-9999 | 10.0-9999 |
| Stacking length range(mm) | 300-4000 | 300-4000 | 300-4000 | 300-4000 |
| Cut-to-length precision(mm) | ±0.3 | ±0.3 | ±0.5 | ±0.5 |
| Leveling precision(mm/m2) | 4-5 | 4-5 | 3-4 | 3-4 |
| Leveling speed (2000mm/min) | 35pcs | 35pcs | 35pcs | 35pcs |
| Coil weight(T) | 10 | 10 | 20 | 20 |
| Leveling roller Dia.(mm) | 85 | 90 | 90 | 100 |
Note: HRC coil cut-to-length lines are also available. (Max. thickness 30mm)
