High Speed Slitting Line

• Coil width 600-1600mm
• Slitting strips 2-30
• Line speed 10-120
• Coil weight 10-30T

Technical Data

Model/name	2×1300	2×1600	3×1300	3×1600
Coil thickness (mm)	0.3-2	0.3-2	0.5-3	0.5-3
Coil width(mm)	600-1300	600-1600	600-1300	600-1600
Slitting strips	2-30	2-30	2-15	2-15
Strip width precision	±0.1	±0.1	±0.15	±0.15
Line speed	10-120	10-120	10-120	10-120
Coil weight(T)	10	15	20	30
Coil I.D.(mm)	Ф508	Ф508	Ф508,Ф610	Ф508,Ф610
Recoiling I.D.(mm)	Ф508	Ф508	Ф508	Ф610
Main shaft Dia	205	240	240	240

Note: HRC slitting line is also available. (Max. thickness: 16mm.)
