Electric Powered Air Compressor Manufacturer

Electric Powered Air Compressor

Request a Quote

View All: http://shimgecompressor.com/1-5-oil-free-electric-powered-compressor.html

Overviews
The electric powered air compressor provides power for mining, rock drilling and a variety of construction applications. It also provides power for a variety of tools, including down-the-hole drill rigs, anchor drill rigs, rock drills, shotcrete machines, sand blast machines and other machines. The air compressor features a low cost, pollution free performance, and is easy to operate, featuring a large air output.

Technical parameters

Model	Working pressure	Flow rate	Air outlet valve (inch)	Engine	Motor maximum speed	Transportation dimension (skid-mounted)
Model	bar	m3/min	Qty.* size	power voltage	rpm	length mm	width mm	height mm	weight kg
LUY100D-7	7	10	1×G1 1/2 1×G3/4	55KW 380V/50HZ	2970	2235	1300	1623	1520
LUY120D-13	13	11	1×G2 1×G3/4	90KW 380V/50HZ	2970	2200	1170	1400	1440
LUY130D-7	7	13	1×G2 1×G3/4	75KW 380V/50HZ	2970	2200	1170	1400	1340
LUY130D-10	10	13	1×G2 1×G3/4	90KW 380V/50HZ	2970	2200	1170	1400	1440
LUY135D-13	73	13.5	1×G2 1×G3/4	110KW 380V/50HZ	2970	2680	1660	1800	2285
LUY165D-10	10	16.5	1×G2 1×G3/4	110KW 380V/50HZ	2970	2680	1660	1800	2285
LUY203D-7	7	20.3	1×G2 1×G3/4	110KW 380V/50HZ	2970	2680	1660	1800	2285
LUY230D-8	8	23	1×G2 1×G3/4	132KW 380V/50HZ	2970	2680	1660	1800	2285
LUY210D-10	10	21	1×G2 1×G3/4	132KW 380V/50HZ	2970	2680	1660	1800	2285
LUY165D-14	14	16.5	1×G2 1×G3/4	132KW 380V/50HZ	2970	2680	1660	1800	2285
LUY150D-16	16	15	1×G2 1×G3/4	132KW 380V/50HZ	2970	2680	1660	1800	2285
LUY170D-17	17	17	1×G2 1×G3/4	160KW 380V/50HZ	2970	3280	1670	1870	2850
LUY250D-10	10	25	1×G2 1×G3/4	160KW 380V/50HZ	2970	3985	1800	2200	3900
LUY210D-14	14	21	1×G2 1×G3/4	160KW 380V/50HZ	2970	3985	1800	2200	3900
LUY280D-8.5	8.5	28	1×G2 1×G3/4	160KW 380V/50HZ	2970	3985	1800	2200	3900
LUY280D-10	10	28	1×G2 1×G3/4	180KW 380V/50HZ	2970	3985	1800	2200	4000
LUY238D-14	14	23.8	1×G2 1×G3/4	180KW 380V/50HZ	2970	3985	1800	2200	4000
LUY220D-21	21	22	1×G2 1×G3/4	200KW 380V/50HZ	2970	3985	1800	2200	4100
LUY250D-21	21	25	1×G2 1×G3/4	220KW 380V/50HZ	2970	3985	1800	2200	4250
LUY290D-21	21	29	1×G2 1×G3/4	250KW 380V/50HZ	2970	3985	1800	2200	4300

(Please enter your desired product model)

Features of electric powered air compressor

Easy to maintain
Motor driven
The electric powered air compressor has an outstanding cooling capacity, allowing the compressor to operate at high temperatures.
It features a highly efficient air filter and uses a 3 stage air filtration system in order to prevent most dust and pollutant types from entering the main engine.
The compressor is equipped with a flexible coupling, which effectively reduces equipment vibration, thereby improving reliability.
Due to the compressor gear transmission, the air compressor features a high transmission efficiency and reliable performance.
This compressor uses a CS6000 controller and LCD liquid crystal display, and offers multi-language selections. In addition, it is fully automatic, and will fully monitor different work conditions
This electric powered air compressor uses coordinated control, meaning it can control anywhere from 2 to 6 pieces of equipment at one time, thereby reducing energy consumption.
The flexible, built in damping system and mobile system allow users to easily move the compressor and transport it to the construction site.
This compressor features a low noise performance.
It comes equipped with a pre-filtered air system and cold start synthetic oil.
It conforms to IP54 protection levels.
