Underground Electric Wheel Loader
Overviews
LGMRT underground electric wheel loaders are powered using electric motors with a load capacity of 5 to 10 tons. These loaders are primarily used for underground loading, handling and dumping, and capable of working even in harsh underground environments. Our electric underground loader design is based on the Sandvik LH series. Due to the wheel loader's outstanding performance, it is a popular choice among customers in North America and China, garnering significant praise.
Clean and green
Because we use an electric motor, there are no exhaust emissions. This ensures air in the mine remains cleaner, which in turn reduces ventilation costs and facilitates a higher miner productivity.
Low operating cost
Zero emissions mean the need for underground ventilation is significantly reduced, which in turn eventually leads to a significant investment return.
| Model | Payload capacity (kg) | Standard bucket capacity (m3) | Length (mm) | Width (mm) | Height (mm) | Unloaded weight (kg) | |
| UL50E | 4500 | 2.2 | 7380 | 1810 | 2000 | 13660 | |
| UL70E | 7000 | 3.5 | 8790 | 2200 | 2290 | 19500 | |
| UL100E | 10000 | 4.3 | 9780 | 2470 | 2370 | 27100 |
Higher reliability
This underground loader uses hydraulic components sourced from internationally renowned brands, including the US Permco oil pump, the US Eaton hydraulic tubing, the Germany Rexroth manifold valves and the American Dana drive axle.
Easier operation
All instrument and alarm functions are integrated into a single control panel, making it easier to observe the vehicle and working conditions at any time. The steering and working handle position are designed to be ergonomic and easy to operate. The underground loader features a wider working angle, which reduces blind areas and makes the equipment safer to operate.
Better cable protection
The adjustable two-stage cable over-roll protection effectively controls cable rollovers caused by improper operation, and ensures a longer cable service life. A large cable reeler diameter ensures excellent bending protection for the cable, and a special cable reel design with excellent ventilation ensures better cable fan heat.
