5kW Light Tower Gasoline Generator Manufacturer

5kW Light Tower Gasoline Generator

Request a Quote

Original: http://db-dieselgenerators.com/6-1-mobile-light-tower-with-5kw-gasoline-generator.html

Features

The mobile light tower is equipped with four 1000W high-efficiency Philips LED lamps, with each head individually adjustable, providing full 360° illumination tailored to your needs.
Utilizes a 3-section pneumatic telescopic mast, offering a maximum extension height of 4.5 meters. Lamp angles can be flexibly adjusted for a lighting radius of 45–65 meters.
The gasoline generator can operate continuously for up to 13 hours on a full tank of fuel or alternatively be connected directly to 220V mains power for consistent lighting.
The light tower supports wireless remote control within a 50-meter range, allowing independent on/off operation of each lamp. Both electric and manual pumps enable quick mast raising and lowering.
The generator base is fitted with either universal casters or steel wheels, allowing operation across uneven ground, gravel, and even rail tracks, enhancing stability.

Specifications

Model		DB6600ZM
Generator	Rated Voltage (V)	230
	Frequency (Hz)	50
	Max. Output Power (kW)	5.5
	Rated Output Power (kW)	5
	Power Factor (COSφ)	1.0
	Insulation Class	F
Engine	Engine Model	190F
	Bore Size×Stroke (mm)	90×66
	Displacement (cc)	420
	Fuel Consumption (g/kWh)	374
	Ignition	Electronic ignition
	Engine Type	1 cylinder, 4-stroke, air-cooled, OHV (overhead valve)
	Fuel Type	90# Gasoline
	Oil Capacity (L)	0.6
	Starting System	Recoil/Electric Start
Accessory Configuration	Fuel Capacity (L)	25
	Battery	12V-9AH
	Oil Alarm	√
	Fuel Indicator	√
	Control Panel	√
	Wheels	√
Others	Noise Level (dBA/7m)	75dBA/7m
	Lamp Protection Class	IP65
	Lighting Power (W)	1000×4pcs
	Max. Height of Telescopic Mast (m)	4.5
	Telescopic Mast Size (mm)	1350×500×800
	Lamp Size (mm)	600×530×450
	Weight (kg)	120
