GZ Roll-Forming provides customers with roll forming systems for drawer slides. According to the drawer slide shape and material, we will provide different roll forming machine, satisfying different needs.

The roll forming line for drawer slides consists of the material loading unit, roll forming machine, hydraulic punching and cutting mechanism. The cut length is adjustable and with fully automatic production processes, production parameters and output are easily set on the touch screen.

Gallery
Technical Parameters
Forming material 0.8-3mm cold/hot-rolled, galvanized, stainless steel strip
Forming passes 10-20
Production speed 6~15m/min
Cut off Hydraulic
Processing quality Straightness: L≤2000mm, curvature≤2mm; deflection≤2º No surface wrinkles, bumps, scratches or other defects Cross-section size and hole position meet customer’s requirements or national standards
Remark: Custom design is available according to client’s actual requirements. The data listed above is only for reference.
