Cold Glue Laminating Machine
| Working table size | 190*1350mm |
| Panel length | 600mm or more |
| Panel width | 1220mm |
| Panel thickness | 2.5—50mm |
| Material feed speed | 0—20m/min |
| Motor power | 3.7kw |
| Heating power | 10.5kw |
| Machine weight | 4000kg |
| Material width | 1280mm |
| Overall dimension | 10800*1900*1700mm |
| Roller diameter | 190 |
This laminating machine is designed for bonding decorative veneer, paper, foil, film and other surface materials to various types of panel. It is an ideal wood processing machine for small and medium-sized furniture factories or speaker manufacturers.
Configuration
Infeed & outfeed conveyor, glue spreader, laminating unit, automatic material cutting unit, roller press
Applicable materials
PVC film, paper, PET, acrylic board, cling film, UV board, decorative veneer, shrink film, etc.
Functions
Automatic material feeding, gluing and pressing
Dust removal
Dust cleaning roller: Φ190*1400mm
Speed control: 0-20m/min
It can remove dust from panel surface, providing better bonding effect.
Glue conveying
Roller size: Φ80*1500mm
Conveyor size: 2000*1600mm
Gluing unit
Rubber roller
Conveyor roller
Speed control: 0-20m/min
Laminating unit
Upper rubber roller
Upper steel roller
Bottom roller 2pc
Speed control: 0-20m/min
