Laminating Line for Hot-Melt (PUR) Lamination, PUR-1220
Request a Quote
Samples
Technical Data
| Model | PUR-1220 |
| Max. processing width | 100-1220mm |
| Feeding speed | 5-26m/min |
| Total power of drive | 26kw |
| Oil heating power | 37.5kw |
| Drying tunnel heating power | 18kw |
| Total machine power | 81.5kw |
| Overall size | 17000*2690*2840mm |
| Weight | 9000kg |
This laminating line is typically designed for laminating of various panels, such as high-gloss veneer sheet, cabinet door panels, interior door panels, honeycomb sheet, foam sheet, etc. This laminating system consists of feeding table, dust remover, gluing machine and pass-through press machine.
By utilizing PUR hot-melt adhesive, this laminating line is an ideal option for replacing traditional long-time lamination presses with ordinary adhesive. Through continuous pressing process by 6-meter pass-through pressing unit, this lamination system can provide a high efficiency and energy-saving lamination solution.
Features
- PUR/SOLVENT/PVAC/UF adhesive versatile purpose
- Gluing evenly and accurately
- Heating temperature is adjustable based on actual production needs
- Adjustable working speed
- Double application of coil and sheet lamination
- Applicable substrates: MDF, HDF, plywood, real-wood, particle board, WPC board, plastic board, door board, metallic panel, aluminum panel etc.
- Lamination material: PVC, PET, PETG, veneer, composite fabric, leather, paper, alum foil, cloth, etc.
