ZG3210-9C Crawler Excavator
Request a Quote
Video
- Our hydraulic crawler excavator is equipped with a reliable original Cummins engine.
- The excavator comes with a reliable hydraulic system that contains superior-quality pumps, motor and valves.
- The digger is designed with an electronic monitoring and control system which has multifunctional LCD display function.
- With a stepped-up device, the hydraulic excavator suits use in mines.
- Strengthened X-shaped box structure
Consulting Products Information
Technical Parameters of Hydraulic Excavator:
| Model | ZG3210-9C |
| Length×Width×Height(mm) | 9520×2800×3030 |
| Operating weight (Kg) | 21000 |
| Rated bucket capacity(m3) | 0.91 |
| Max.digging depth(mm) | 6690 |
| Max.digging radius(mm) | 9953 |
| Max.digging height(mm) | 9642 |
| Max.dumping height(mm) | 6813 |
| Bucket digging force(KN) | 137 |
| Stick digging force(KN) | 102 |
| Gradient capacity(%) | 70 |
| Diesel engine | Cummins 6BTAA5.9-C150 |
| Rated output(KW) | 112 |
