Telescopic Handler SWTH3910

Max. lifting height: 10.2m
Max. lifting capacity: 4000kg
Engine power: 73.6kW

Specially designed twin luﬃng cylinders, large-sized front all-terrain tyres and removable outriggers help the telehandler stay stable;

Self leveling function allows the attachment mounted on the end of the boom such as fork to be automatically leveled as the boom raises or lowers, significantly shortening operating cycle time, ensuring high operating efficiency and safe working condition, while avoiding serious injuries or damages caused by operator's misoperation;

Spacious operator's cab offers optimal visibility, and automatic air conditioner is equipped to maximize driving comfort;

Mechanical control lever and rocker switches are easy to use;

Large screen display shows all parameters of the telescopic handler, alarm function is available;

Performance Parameters

Dimension (L×W×H)		mm	7215×2320×2450
Basic parameters	Machine weight (unladen)	kg	10600
	Rated load capacity	kg	4000
	Max. handling height	m	10.2
	Max. overhang length	m	5.2
	Max. overhang length load	kg	2000
	Ground clearance	mm	300
	Turning radius (outside)	m	5.06
	Traction	KN	40
Performance	Boom raising speed	s	9
	Boom lowering speed	s	10
	Boom retracting speed	s	14
	Boom extending speed	s	12
Transmission system	Transmission mode		Hydrodynamic transmission
	Gear (forward and reverse)		2/2
	Max. traveling speed	km/h	36
	Gradeability	%	30
Engine	Brand		Yuchai
	Model		YCD4J23T8-100
	Power		73.6/2200
	Max. torque	N.m/rpm	380/ ≤1650
	Fuel injection mode		Electronic fuel injection
	Cooling mode		Water cooling
System capacity	Hydraulic oil	L	180
	Fuel	L	140
	Engine oil	L	7.5
	Cooling system	L	15
Fork	L×W×T	mm	1220×125×50
	Max. distance between forks	mm	1200
	Rotation angle	°	117
Tyre	Front wheel specifications		15.5-25-16PR
Tyre	Rear wheel specifications		9‘00-20-11PR

Statement of technical specification: all parameters above are subject to change due to the continuous improvement of the product, please to get the latest info updates.
