Telescopic Grapple Loader
- On working
- On working
Recommended application
The HY2500 telescopic grapple loader has a load weight of 2000-2500kg, a bucket capacity of 1.0m3 which can be lifted to a maximum of 45m height in 5s rapidly, working efficiently and flexibly. A machine can replace at least 20 workers’ labor, which has extensive applications in farms, ranches, logistics warehouses, municipal maintenance and other work sites.
The loader is equipped with front standard bucket and fast connector, allowing the users to conveniently replace attachments with different functions according to the different operating requirements.
Technical parameters| Rated Load | 2000kg-2500kg |
| Total Weight | 5230 kg |
| Rated Bucket Capacity | 1.0 m3 |
| Bucket Width | 2150mm |
| Max Breakout Force | 60 KN |
| Max Grade ability | 30° |
| Max Dumping Height | 4500 mm (fully raised height to the pin) |
| Raising Time | < 5.0s |
| Overall Dimensions (L×W×H) | 5800×2150×2750 mm |
| Minimum Turning Radius | 4950 mm |
| Engine | Model | DONGFANGHONG YT4B2-24 |
| Type | Four-cylinder, Inline, Water-cooled, Four-stroke Diesel Engine | |
| Rated Power | 60 kW | |
| Rated Speed | 2400 rpm | |
| Minimum Fuel Consumption Ratio | ≤ 251.6 g/kW·h | |
| Transmission System | Hydraulic Torque Converter | ZL280 Integrated Hydraulic Torque Converter |
| Gear Shift | 1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed | |
| Max. Speed | 25 km/h | |
| Drive Axle | Model of Axle | ZL20 Hub Reduction Axle (big) |
| Wheel Tread | 1500 mm | |
| Wheel Base | 2350 mm | |
| Drive | Mode | 4-wheel Drive |
| Brake System | Service Brake | Foot Pedal Vacuum Booster, Air Over Hydraulic Caliper Disc Brake on 4 Wheels |
| Parking Brake | Hand Lever Flexible Shaft Controlled Disc Brake | |
| Tyre | Type Specification | 16/70-20-16PR |
| Front Tyre Pressure | 0.40 Mpa | |
| Rear Tyre Pressure | 0.35 Mpa |
1. The Perkins brand of 404D-22 engine, cooperated with the 220V engine heater, operates steadily.
2. It is equipped with 12-16.5 vacuum tires, using four wheel drive, adapted to various working conditions.
3. The cab with deluxe seats is configured with LED lights, adjustable steering wheel, hydraulic joystick and microcomputer controlled operating system, facilitating the drivers to operate.
Hongyuan Vehicle has been manufacturing super quality wheel loaders, is offering front end loaders for agricultural and heavy construction industry. By changing the associated implements on the loaders, we can offer a wide range of special purpose loaders, like sugar cane grab loader, log grapple loader, rough terrain forklift truck, snow plow, rock breaker and so on. With rich export experience and quality assurance, we provide custom need farming and construction equipment with competitive prices.
