Pivot Tire, Non-Pneumatic Irrigation Tire (Rubber)

Request a Quote

View All: http://rainfineirrigation.com/7-10-pivot-tire/195141/index.html

We provide three different options for our rubber pivot tires:
1. 11.2×38: Good clearance and flotation
2. 14.9×24: Tubeless tire 4ply, for heavier and longer spans
3. 16.9×24: For longer spans more flotation

Features of Pivot Tire
1. 14.9"× 24" tubeless tire with hot dip galvanized tire rim
2. Specially designed valve stem protects air leaks in hot and cold climate changes.
3. The thickness of the wall is 17-27mm to withstand heavy duty working conditions.
4. New style of wheel treads increases the capacity of moving up inclined land up to±18o.
5. A dry wheel package is used to keep the dry trace for irrigation equipment tires.

Technical Parameters of Pivot Tire

Motor	Drive speed (RPM/50Hz)	Power	Ratio	Wheel speed (RPM)	Tire size	Distance of wheel per rev	Last tower speed at 100% timer set up
A	25 RPM	0.75HP	40:1	0.50	11.2×24	3.23m	97 m/h
					11.2×28	4.42m	133m/h
					14.9×24	3.60m	108m/h
					16.9×24	3.81m	114m/h
B	33 RPM	1HP	40:1	0.66	11.2×24	3.23m	128m/h
					11.2×28	4.42m	175m/h
					14.9×24	3.60m	142m/h
					16.9×24	3.81m	150m/h
C	49RPM	1HP	29:1	0.98	11.2×24	3.23m	190m/h
					14.9×24	3.60m	212m/h
					16.9×24	3.81m	224m/h

Motor	Drive speed (RPM/50Hz)	Power	Ratio	Wheel speed (RPM)	Tire size	Distance of wheel per rev	Last tower speed at 100% timer set up
A	30 RPM	0.75HP	40:1	0.60	11.2×24	3.23m	116.4 m/h
					11.2×28	4.42m	159.6m/h
					14.9×24	3.60m	129.6m/h
					16.9×24	3.81m	137.4m/h
B	43 RPM	1HP	40:1	0.86	11.2×24	3.23m	166.8m/h
					11.2×28	4.42m	228.6m/h
					14.9×24	3.60m	186.0m/h
					16.9×24	3.81m	196.8m/h
C	59RPM	1HP	29:1	1.18	11.2×24	3.23m	229.2m/h
					14.9×24	3.60m	255.0m/h
					16.9×24	3.81m	270.0m/h
