Silo Dehumidification System
Request a Quote
Features
- User-friendly human machine interface for precise temperature control.
- The qualified honeycomb rotor provides stable dehumidification performance, is easy to clean and has a long service life.
- The silo dehumidification system is equipped with a detachable cooler that is easy to maintain and ensures a lower return air temperature.
- A high-density return air filter protects the honeycomb rotor from dust or contamination.
- Double-layer insulated down-blowing stainless-steel dryer.
- A hot air closed loop conveying system is optional for hot material conveying, eliminating the possibility of moisture re-absorption that would contaminate the resin.
- A food-grade hopper dryer is optional to meet the production needs for food-grade products.
- The air filter is easy to clean and replace. It also features a transparent window for easy monitoring.
- Delivering a dewpoint of -40°C after air dehumidifying.
Technical specifications
Model | Loading Capacity | Electricity | Drying Capacity | Compressed Air Supply | Dimensions | Weight(kg) | With Injection Molding Machine (Ton) | ||||||
Liter | kg | Heater | Blower | Feed Blower | Compressor | Traffic Demand | L | W | H | ||||
Dried Supply | |||||||||||||
YKSG630-15 | 25 | 15 | 1.5 | 0.05 | 1.1KW | 5.0 | 0.75KW | 70L/min | 800 | 580 | 1500 | 180 | 10-50 |
YKSG630-25 | 46 | 25 | 2.5 | 0.08 | 1.1KW | 9.2 | 1.5KW | 120L/min | 980 | 750 | 1800 | 230 | 50-100 |
YKSG630-50 | 86 | 50 | 4 | 0.1 | 1.1KW | 17.2 | 2.2KW | 190L/min | 980 | 750 | 2000 | 280 | 100-150 |
YKSG630-75 | 130 | 75 | 5 | 0.1 | 1.1KW | 24.8 | 2.2KW | 190L/min | 980 | 750 | 2100 | 280 | 100-150 |
YKSG630-100 | 175 | 100 | 6 | 0.2 | 1.5KW | 35 | 3.7KW | 300L/min | 1100 | 750 | 2100 | 350 | 200-300 |
YKSG630-150 | 250 | 150 | 8 | 0.2 | 1.5KW | 48 | 3.7KW | 420L/min | 1100 | 750 | 2100 | 350 | 300-400 |
YKSG630-200 | 340 | 200 | 10 | 0.33 | 1.5KW | 60 | 5.5KW | 520L/min | 1300 | 1000 | 2100 | 460 | 400-500 |
