Handheld Multichannel Gamma Ray Spectrometer
Handheld multichannel gamma ray spectrometer is a 1024-channel γ spectrometer capable of both spectral signal collection and field processing. The spectrometer consists of main unit and the scintillation probe. The main unit, a Windows Mobile OS PDA with embedded GPS, communicates with the probe via Bluetooth. The field data collecting, analyzing and processing abilities are greatly enhanced, while the troubles in communication cable connection are effectively avoided. The operation interface is viewable, and the instrument can be convenient controlled through a touch panel.
Application● Investigation of radioactive mineral resources, e.g. uranium (U), thorium (Th) and potassium (K).
● Investigation of underground water
● γ ray energy analysis of residences and construction materials
| Energy resolution | < 9% (173Cs γray) |
| Measurable energy range | Total channel≥30keV; K channel: 1370～1565keV; U channel: 1660~1880 keV; Th channel: 2420～2810 keV |
| Multichannel | 256, 512, 1024 optional; Maximum enumeration of each channel is 65535. |
| Measuring time | 1~65535s optional |
| Operating temperature | -5 ~ 50℃，≤95％RH |
| Probe volume | Φ100×400mm |
| Probe weight | 3.9kg |
| Probe battery | 3500mAh (continuously operating for 12h) |
| PDA | Dopod T8288 |
