Wheel Dozer, FK14-91200
Request a Quote
Basic Information
-
- Rated loading weight
- 12000kg
-
- Height of shovel blade
- 1000mm
-
- Rated power
- 250kW
-
- Max. turning angle
- 35°±1
-
- Max.travel speed
- 33km/h
-
- Overall weight
- 32000kg
Technical Specifications
- Rated power: 250/2100kw/rpm
- Engine model: Yucai
- Rated loading weight: 12000kg
- Height of shovel blade: 1000mm
- Blade width: 3600mm
- Steering system: full hydraulic steering system
- Min. turning radius: 7268mm
- Max. turning angle: 35°±1
- Displacement: 250L/min
- System working pressure: 20.3MPa
- Brake system: air assisted oil disc on four wheels
- Parking brake: inner expand hoof, air brake control
- Max. travel speed: 33km/h
- Max. digging depth of dozer blade: 400mm
- Overall width: 9800mm
- Overall height: 3886mm
- Overall weight: 32000kg
