ZG135HF Forestry Excavator
Equipped with wide tracks, a reinforced undercarriage, and upgraded cooling and lighting systems, the forestry escavator is purpose-built for rugged, obstruction-filled terrains common in forest operations, delivering enhanced traction, stability, and resilience in off-road conditions.
- Operating weight 17200 kg
- Rated power 86kW@2200r/min
- A-Overall length 8375 mm
Fitted with 960 mm wide tracks to significantly reduce ground pressure down to 29.7 kPa while the 20-ton-class travel motor boosts tractive force to 182 kN without compromising travel speed.
Features a heightened and reinforced forestry-specific undercarriage with welded box-type anti-collision beams, improving resistance to impact and ensuring greater reliability and terrain adaptability.
Equipped with an enlarged radiator system optimized for forest working conditions. The intake side access door and roof intake are fitted with fine mesh dust screens to prevent foreign objects from clogging the radiator.
Additional heavy-duty LED lighting units are installed to enhance visibility and operational safety in low-light forest environments.
- Model ZG135HF
- Operating weight 17200kg
- Bucket capacity Depending on attatchment
- Engine model Cummins
- Rated power 86kW@2200r/min
- Fuel tank capacity 290L
- Travel speed 4.4/2.6km/h
- Swing speed 12r/min
- Gradeablity 70%
- Bucket digging force at power max (ISO) 100kN
- Average grounding pressure 29.7kPa
- Hydraulic pump model K5V80DTP1
- Max. hydraulic flow 2*160L/min
- Setting pressure 34.3MPa
- Hydraulic tank capacity 165L
- A-Overall length 8375mm
- B-Overall width 3010mm
- C-Overall height (to the top of boom) 2980mm
- D-Overall height(to the top of cab) 3297mm
- E-Counterweight ground clearance 1247mm
- F-Min. ground clearance 636mm
- G-Tailswing radius 2365mm
- H-Track grounding length 3010mm
- J-Track length 3735mm
- K-Track gauge 2200mm
- L-Track width 3010mm
- M-Track shoe width 800/960mm (optional)
- N-Turntable width 2739mm
