This roll forming line is used by Midea Group for manufacturing dishwasher components. It consists of a material loader, roll forming machine, notching press, cutting mechanism, bending mechanism and finished product stacker. The roll-forming line features fully automatic control, and products are easily manufactured in different specifications with easily adjustable product length and width. The product setting and production output are both easily set on the touch screen, while HMI ensures easy operation. The PLC, inverter and other electrical components are produced and imported from Germany and Japan, ensuring long-term stability and performance of the roll forming line.

Gallery
Technical Parameters
Forming material 0.3-0.6mm stainless steel strip
Forming passes 8-36
Production speed 4~6m/min
Cut off Hydraulic cut-off
Processing quality Straightness: L≤2000mm, curvature≤2mm; deflection≤2º No surface wrinkles, bumps, scratches or other defects Cross-section size and hole position meet customer’s requirements or national standards
Remark: Custom design is available according to client’s actual requirements. The data listed above is only for reference.
