DXDK350 Alu-Alu Strip Packaging Machine
Pharmaceutical Packaging Machinery Since 1998
- Cutting frequency: 20–60 cuts/min (adjustable)
- Packing speed: 120–180 packs/min
The Alu-Alu strip packaging machine is suitable for composite films, plastic films, paper films, and other packaging materials. It can package various shapes and sizes of capsules, tablets, and other solid products.
The machine features variable frequency speed control with adjustable stroke, vibration feeding mechanism, and photoelectric monitoring. It automatically performs feeding, heat sealing, cutting lines, batch numbering, and trimming. It is suitable for tablets, capsules, and electronic components, providing reliable sealing and light protection.
Packaging of capsules and tablets in pharmaceutical, food, and cosmetic industries, providing light protection and moisture resistance.
- Four-side sealing with simultaneous multi-strip packaging, improving efficiency.
- PLC control enables a high degree of automation.
- Stepless variable frequency drive ensures stable performance and easy operation.
- Photoelectric tracking and floating alignment maintain accurate double-sided pattern positioning.
- Easy mold roller replacement; single heating tube ensures uniform heating and tight sealing.
- Automatic batch numbering and cross/longitudinal tearing lines functions.
- Modern appearance with large color touchscreen and bilingual interface (Chinese/English) for intuitive operation.
| Cutting frequency | 20–60 cuts/min (adjustable) |
| Packing speed | 120–180 packs/min |
| Packing material | Plastic-aluminum composite film |
| Bag length | 30–200 mm |
| Bag width | 40–300 mm |
| Installed power | 5.74 kW |
| Voltage | 380 V, 50 Hz |
| Dimensions (L*W*H) | 1500×1070×2100 mm |
| Weight | 1000 kg |
-
- Feeding station
-
- Sealing station
-
- Batch numbering station
Shou Rushong implemented the DXDK350 strip packaging machine to meet strict requirements for light protection, sealing, production efficiency, and compliance. The precision heat-sealing system ensures each individual blister is tightly sealed with no leakage, effectively protecting photosensitive and easily oxidized medicines.
Adjust the tension settings on the unwinding and rewinding units, reducing tension as needed. Check and adjust the pressure on the feed rollers to ensure even pressure without crushing the film. Inspect the film roll for joints, uneven thickness, or quality issues.
The strip packaging machine is mainly used for light-sensitive or easily oxidized drugs. The heat-sealed blister ensures each individual unit has high light-blocking and airtight performance, effectively protecting the stability of the drug and extending shelf life.
Yes. The strip packaging machine uses a precision heat-sealing system to ensure each blister is tightly sealed, preventing light or oxygen exposure during the product’s shelf life. It fully meets pharmaceutical standards for light protection and airtightness, and is suitable for capsules, tablets, and various shaped solid dosage forms.
