Glass-Lined Reactor Cover
The glass-lined reactor cover is available in the following specifications: AE63L, AE100L, AE160L, AE250L, AE400L, AE630L, AE1000L, AE1600L, AE2500L, AE4000L, and AE5000L. It is manufactured in accordance with ASME and PED pressure vessel standards and is widely used in the chemical, petroleum, pharmaceutical, agrochemical, food, and dye industries, providing an efficient and stable reaction solution for production of different scales.
Featuring a high-strength elliptical head and a precision flange structure, the glass-lined reactor cover can be flexibly configured with different nozzles and accessories according to process requirements. This design combines sealing safety with operating convenience and is suitable for glass-lined reactors with different pressure ratings and operating conditions.
- Reliable structure and strong adaptability
The cover consists of an elliptical head and a high-neck flange and can be securely connected to the vessel body by clamps or bolts to form a complete reaction system. - Flexible process connections
The size and number of nozzles can be customized to meet different process requirements, including feeding, discharge, temperature measurement, cleaning, and inspection. - High-strength nozzle design
The nozzles use an integral forging and flanged glass-lined structure, providing higher strength and fewer defects while helping prevent reverse corrosion caused by material leakage. - High-level sealing design
The flange and nozzles can be designed with a male-and-female sealing face, making them suitable for high-pressure and high-risk operating conditions while improving operational safety.
- AE open type structure
The cover and vessel body have the same diameter, making it easier to install and maintain large-size agitators. - CE closed type structure
The cover uses an integrated top head with a small-diameter dished head design, offering better sealing performance and making it suitable for small-size agitation applications.
