Silicon Rubber Extrusion Line
Request a Quote
Results from silicon jacket extrusionSilicon rubber extrusion line mainly used in extrusion of silicon jacket with various colors that are suitable for refractory cable. The silicon jacket extrusion line is applicable in extreme conditions with temperature ranges from -55℃ to 260℃ without losing its physical properties as well as having flame retardancy. It is a low smoke cable.
Table below shows cable production line we manufactured in the past| Model | 45 | 65 | 80 | 90 |
| Extrusion output | 30kg/h | 80kg/h | 135kg/h | 180kg/h |
| Screw diameter (mm) | 45mm | 65mm | 80mm | 90mm |
| Pay-off bobbin dimensions (mm) | 300-400mm | 400-630mm | 630 – 1000mm | 800-1250mm |
| Finished outer diameter (mm) | 0.8-5.0 | 1.8-8.0 | 3.0-25 | 8.0-35 |
| Vulcanize length | 12M | 16M | 24M | 28M |
| Heating power | 36KW | 48KW | 72KW | 84KW |
| Line speed | 10-200m/min | 10-200m/min | 5-50m/min | 5-50m/min |
| Take-up bobbin dimensions (mm) | 400-630mm | 400-630mm | 630-1000mm | 800 – 1250mm |
