Optical Cable Sheath Extrusion Line

Optical Cable Sheath Extrusion Line
Optical Cable Sheath Extrusion Line
Optical Cable Sheath Extrusion Line
Request a Quote
Finished Wire Style

Dielectric sheath extrusion line mainly used in extrusion of its internal or external sheath. It utilizes wide range of different materials for the extrusion including PVC, PE, XLPE and so on. We provide services such as production line design, matching and installation based on customers' demands on cable type and its parameters as well as the conditions of the workshop.

Parameters
  • Construction speed: 100m/min
  • Production speed: 80m/min (Ф9.0mm)
  • Extrusion output: max.260kg/h
  • Cable core diameter: Ф1.8-Ф25mm
  • Extruder outer diameter: Ф7-Ф30mm
  • Extruder specification: 90×25
  • Pay-off reel dimensions: (PN800~PN2000)mm
  • Take-up reel dimensions: (PN800~PN2000) mm
  • Additional losses: 0.02dB/km
  • Length of production line: 50m
  • Installed power: 120KVA, 50Hz, 380V±5%
Parts of the production line
  • 2000mmm floor rail portal driven pay –off machine
  • 800mm horizontal double wheel tension dancer
  • 24-head yarn rotation pay-off
  • Steel aluminum tape pay-off
  • Steel aluminum tape spot welder
  • Steel aluminum tape accumulator
  • Non-mental tape pay-off
  • Jelly filling device
  • Steel longitudinal taping forming device
  • Steel aluminum tape cigarette wrap device
  • 90*25 extruder
  • Hot water channel and hot water tank
  • (Up 8m + down 8m) cold water channel and water tank
  • Dryer
  • One-way diameter gauge
  • Sparker gauge
  • Ink-jet printer
  • 1250KG caterpillar-tractor
  • Take-up tension dancer
  • 2000mm floor rail portal take-up traverse machine
  • Electrical control system
