WN160TA(50-400)H High Precision Motorized Linear Stage
Request a Quote
High Precision Linear Motor Stages is suitable for providing linear displacement by electric control in automatic displacement control in scientific research, full-automatic measuring and testing equipment, industrial automation and other fields. It has a table size of 60×60HH with 3 kinds of load capacity (3kg, 5kg and 8kg), and a wide travel range from 50mm to 400mm.
Parameter table of WN160TA(50-400)H High Precision Motorized Linear Stage| Table Size | 60×60mm |
| Screw Type | High precision ball screw (lead 2mm) |
| Stepper Motor (1.8°) | STP-35D3016 |
| Resolution | 10μ (Non-microstepping driver) 0.5μ (20 microstepping driver) |
| Maximum Speed | 15HH/sec |
| Repeatability | 2μ |
| Positional Accuracy | 5μ |
| Model | WN160TA50H |
| Travel | 50 mm |
| Load Capacity | 8 kg |
| Weight | 1.4kg |
| Straightness | 5µ |
| Driving Parallelism | 10µ |
| Pitching | 25″ |
| Yawing | 20″ |
| Backlash | 2µ |
| Runout | 3µ |
| Model | WN160TA100H |
| Travel | 100 |
| Load Capacity | 8 kg |
| Weight | 1.7kg |
| Straightness | 5µ |
| Driving Parallelism | 10µ |
| Pitching | 25″ |
| Yawing | 20″ |
| Backlash | 2µ |
| Runout | 3µ |
| Model | WN160TA150H |
| Travel | 150 mm |
| Load Capacity | 5 kg |
| Weight | 2.3kg |
| Straightness | 6µ |
| Driving Parallelism | 15µ |
| Pitching | 50″ |
| Yawing | 25″ |
| Backlash | 2µ |
| Runout | 3µ |
| Model | WN160TA200H |
| Travel | 200 mm |
| Load Capacity | 5 kg |
| Weight | 2.6kg |
| Straightness | 6µ |
| Driving Parallelism | 15µ |
| Pitching | 50″ |
| Yawing | 25″ |
| Backlash | 2µ |
| Runout | 5µ |
| Model | WN160TA300H |
| Travel | 300 mm |
| Load Capacity | 3kg |
| Weight | 3kg |
| Straightness | 6µ |
| Driving Parallelism | 15µ |
| Pitching | 50″ |
| Yawing | 25″ |
| Backlash | 2µ |
| Runout | 5µ |
| Model | WN160TA400H |
| Travel | 400 mm |
| Load Capacity | 3kg |
| Weight | 3.5kg |
| Straightness | 8µ |
| Driving Parallelism | 20µ |
| Pitching | 50″ |
| Yawing | 30″ |
| Backlash | 2µ |
| Runout | 5µ |
Features of WN160TA(50-400)H High Precision Motorized Linear Stage
- Light weight with aluminum alloy material, blackened by anodic oxidation, suit for low vacuum environment.
- Precision ball screw drive, great repeatability and positional accuracy, small axial clearance and long service life.
- Stable and high load capacity with precision linear slide guide. The precision motorized linear stage is suit for single axle load or multi-axis combination.
- Reduce the pitching and yawing of the motorized linear stage through the reasonable mounting of the base plate and the guide, so as to effectively improve the straightness and driving parallelism.
- Realize high speed and high load by adding servo motor and closed-loop control of linear scale.
- Dustproof cover and power-off brake could be added for the motorized stage.
