Stainless Steel Mini Ball Valve
Request a Quote
- Working pressure: 450 PSI
- Temperature range: -4 °F to 250 °F (-20 °C to 120 °C)
- Chrome plated hex brass body
- Chrome plated brass ball, brass stem, PTFE ball seat and Viton stem sealing
- ABS plastic wedge handle
- Male thread at one end, and the other side is drain port without thread
Specifications
Inch/Metric(mm)
| Size | A | B | S | H | L | |||||
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | |
| 1/8" | 1.22 | 30.99 | 0.24 | 6.10 | 0.82 | 20.83 | 1.10 | 27.94 | 0.78 | 19.81 |
| 1/4" | 1.26 | 32.00 | 0.31 | 7.87 | 0.82 | 20.83 | 1.10 | 27.94 | 0.78 | 19.81 |
| 3/8" | 1.26 | 32.00 | 0.31 | 7.87 | 0.82 | 20.83 | 1.10 | 27.94 | 0.78 | 19.81 |
| 1/2" | 1.57 | 39.88 | 0.39 | 9.91 | 0.98 | 24.89 | 1.29 | 32.77 | 0.78 | 19.81 |
| Part # | Part Name | Material |
| 1 | Valve Cap | Brass, Chrome plated |
| 2 | Cap Sealing | Rubber |
| 3 | Ball Seat | PTFE |
| 4 | Ball | Chrome plated Brass |
| 5 | Stem | Brass, Chrome plated |
| 6 | Screw | Steel |
| 7 | Washer | Steel |
| 8 | Handle | ABS Plastic |
| 9 | Stem Seal | Viton |
| 10 | Body | Brass, Chrome plated |
