DAAO6610 Stainless Steel Combination Shower & Eyewash

Compliance: ANSI Z 358.1-2014, EN15154.1/2:2006

Specifications

Height: 2410 mm (can be customized)
Material: 304/316L stainless steel
Pipe wall thickness: 2.5 mm
Water pressure: 0.2 MPa-0.8 MPa
Ambient temperature: 10℃-35℃
Inlet size: NPT 1 1/4”
Drain size: NPT 1 1/4”
Flow rate (eye/face wash): ≥11.4 L/min
Flow rate (shower): ≥75.7 L/min

Options: color, material, dimension, etc.
Material for shower head and bowl: ABS or stainless steel
Shower includes: SUS304 stainless steel pipe (1-1/4"), ball valve, drawbar with a diameter of 8mm, and spray head

Eyewash includes: SUS304 stainless steel pipe, ball valve, bowl with dust cover
Spray nozzle: stainless steel, built-in PP filter
Others: stainless steel foot pedal available for all combination type

DAAO has been a reliable manufacturer of emergency showers and eyewashes for 15 years. We can produce custom products that meets your special needs. Please see more that we have made to find the product you are looking for.
