Fermentation Tanks, Stainless Conical Fermenters

Our stainless steel fermenter is a good choice of microbial fermentation. The smooth interior of the tank allows simple removal of trub and maintaining hygienic conditions.

Form
Various options

If needed, we can provide custom stainless steel fermenters.

    1. Two-stage Stainless Steel FermenterTwo-stage fermenter consists of two fermentation tanks and a control system. The primary and secondary fermenters can work separately or work together.
    1. Multi-stage Stainless Steel FermenterComposed of three or more stainless steel tanks, the multi-stage stainless steel fermenter is capable of the fermentation process mainly from primary stage to tertiary stage. Controlled by independent PLC, fermenters can work separately or work together.
Basic Configurations
  • PH
    • On-line check and measure
    • Peristaltic pumps for adding the acid and base solutions
    • Control range: 2-12pH; measuring accuracy: ±0.01 pH; control accuracy: ±0.1 pH
    • Automatic alarm
  • DO
    • On-line check and measure
    • Combined with rotation speed
    • Range: 0-100% or 0-200%; accuracy: ±1%
    • Automatic alarm
  • Defoaming
    • Automatic control and alarm
    • Stainless steel electrodes
    • Peristaltic pumps for adding antifoaming agents
  • Feeding
    • Manual control and automatic alarm
    • Stainless steel electrodes
    • Peristaltic pumps for feeding
  • Temperature
    • PID control
    • Measuring range: 0-150℃; control range: 15-45℃; control accuracy: ±0.2℃
    • pt100Ω temperature probe
    • Built-in electric heating device for controlling the temperature inside
  • Rotation Speed
    • Automatic control and alarm
    • Servo motor
  • Pressure
    • Pressure gauge, manual control (standard)
    • Pressure transducer, automatic control (optional)
  • Air Flow
    • Rotameter, manual control (standard)
    • Mass flow meter, automatic control (optional)
    • PALL filter with the accuracy of 0.2μm
  • Sterilizing Mode

    Off-site sterilization

  • Control Mode

    Siemens PLC, 10.4“ color LCD touch screenPH

  • Computer
    • Configure recording function (optional)
    • Siemens remote control software configure recording function (optional)
    • Printer (optional)
