Check valve, S series comes in a structure the same as that of cone valve. With the fluid flowing only in one direction, the valve allows for little pressure loss.

This check valve is mainly used at pump ends as back pressure and bypass valve. It is widely applied in industrial equipment.

Main Features
1. The one-way valve allows fluid to pass through it only in one direction. Adverse flow is prevented
2. 5 cracking pressure

Technical Parameters of Non-Return Check Valve, S Series
Dimension
6-30
Max pressure (PMAX) bar 31.5
Max flow L/min up to 450

How to Choose the Right Specification
You can determine the model you want according to the table below. Please feel free to contact us if you have any questions.

Characteristic Curve (tested at ν=41mm2/s, t=50℃)

After Sales Service
1. Our valve product comes with 1 year warranty. If there are any quality issues during the warranty period, we will replace or repair the accessories for free
2. We commit that your email will be replied once we have received it, and we will come up with a solution for your problems as soon as possible
