Check Weigher
Request a Quote
- Soonk's check weigher is used for checking whether a product's weight conforms to the saved parameters. The separation system will automatically reject any products that are not within the specified parameters.
- The advanced digital load cell allows for a faster and more stable operation. Easy operation and troubleshooting is achieved using the LCD touch screen.
- Self-diagnosis, error alter and countermeasure display function (Rom/Ram A/D photocell error, etc.)
Technique specification
| Model | SK-XB200 | SK-XB1000 | SK-XB2000 | SK-XB6000 | SK-XB30000 |
| Weighing scope | 2-200g | 10-1000g | 10-2000g | 100-6000g | 5000-30000g |
| Speed (bags/min) | 160bags/min | 80bags/min | 70bags/min | 50bags/min | 30bags/min |
| Min. scale | 0.01g | 0.1g | 0.1g | 0.1g | 0.1g |
| Number of default modes | 20 | 20 | 20 | 20 | 20 |
| Optional reject mechanism | Air blast/Pusher/Diverter/Drop | ||||
| Conveyor (mm) | W100*L300mm | W220*L450mm | W300*L450mm | W400*L650mm | W500*L800mm |
| Total power | 220V，50Hz/60Hz,0.8kW | ||||
If you are interested in our checkweigher, please feel free to contact us!
