Variable Displacement Axial Piston Pump for Closed Circuit

Request a Quote

View All: http://hydraulicsystem-en.com/1-1-10-variable-displacement-pump.html

The HL-A10VG variable displacement pump is built for closed-loop hydraulic systems, giving you precise control and smooth operation in demanding applications. With multiple control options and an integrated pressure cut-off function, this pump ensures efficiency, adaptability, and reliability for yOur Hydraulic Products.

Displacement 45 cm³/rev
Nominal pressure 350 bar
Max. allowable pressure 400 bar

Technical Data

Size					45
Geometric displacement	Variable pump		V_{g max}	cm³/rev	45
Geometric displacement	Boost pump, standard (at p = 20 bar)		V_{g sp}	cm³/rev	13.8
Rotation speed	Maximum at V_{g max}		n_max continuous	rpm	3300
	Limited maximum		n_max limited	rpm	3550
	Intermittent maximum		n_max interm.	rpm	3800
	Minimum		n_min	rpm	500
Flow	at n_{max continuous} and V_{g max}		q_{v max}	L/min	152
Power	at n_{max continuous} and V_{g max}	Δp=300 bar	P_max	kW	75.9
Torque	at V_{g max}	Δp=300 bar	T_max	Nm	220
Torque		Δp=100 bar	T	Nm	73.2
Moment of inertia for drive shaft			J	kg·m²	0.0033
Max. angular acceleration				rad/s²	4000
Max. rotation speed variation				rpm	14
Case volume			V	L	0.75
Weight without through drive (approx.)			M	kg	27

Features

axial piston variable displacement pump Swashplate design provides consistent hydrostatic power in closed circuits.
proportional flow control Flow rate adjusts in proportion to your system’s drive speed and displacement, offering smooth and accurate regulation.
infinitely variable displacement adjustment Output flow increases from zero to maximum based on the swashplate angle, giving you full control over hydraulic performance.
seamless flow direction changes Effortlessly reverse hydraulic flow by adjusting the swashplate movement.
versatile control options A range of control modes let you customize your system’s response and efficiency.
integrated pressure relief system Each high-pressure side is equipped with dual relief valves to protect your hydrostatic transmission from overload.
dual-function relief valves These also serve as charge valves, ensuring steady system operation.
built-in charge pump Maintains charge pressure and supplies control oil for greater reliability.
pressure limiting function An internal charge relief valve regulates the maximum charge pressure to prevent excess strain.
standard pressure cut-off valve Integrated by default to enhance system protection.

Applications

Aerial Work Platform

Construction Machinery

Agricultural and Forestry Machinery

This axial piston pump gives you the performance, efficiency, and flexibility needed for closed-loop applications. Let’s explore how it can optimize your hydraulic system. Get in touch today!
